23
Publication 1763-IN001C-EN-P - June 2015
Specifications
General Specifications
Description 1763-
L16AWA L16BWA L16BBB L16DWD
Dimensions Height: 90 mm (3.5 in.), 104 mm (4.09 in.) (with DIN latch open)
Width: 110 mm (4.33 in.), Depth: 87 mm (3.43 in.)
Shipping Weight 0.9 kg (2.0 lbs)
Number of I/O 12 inputs (10 digital and 2 analog) and 6 outputs
Power Supply
Voltage
100...240V ac (-15%, +10%) at 47...63 Hz 24V dc (-15%,
+10%) Class 2 SELV
12V to 24V dc
( -15%, +10%)
Class 2 SELV
Heat Dissipation Refer to the MicroLogix 1100 Programmable Controllers User Manual, Publication
1763-UM001.
Power Supply
Inrush Current
120V ac: 25 A for 8 ms
240V ac: 40 A for 4 ms
24V dc:
15 A for 20 ms
Power
Consumption
46 VA 52 VA 35W
24V dc Sensor
Power
none 250 mA at 24V DC
400 µF max.
none
Input Circuit Type Digital: 120V ac
Analog: 0...10V dc
Digital: 24V dc
sink/source
(standard and
high-speed)
Analog: 0...10V dc
Digital: 24V dc
sink/source
(standard and
high-speed)
Analog: 0...10V dc
Digital: 12/24V dc
sink/source
(standard and
high-speed)
Analog: 0...10V dc
Output Circuit
Type
Relay Relay Relay/FET Relay
Pilot Duty Rating Ordinary location – B300, R150
Hazardous location – C300, R150
Temperature,
Operating
-20... +65 °C (-4 ...+149 °F)
Temperature,
Storage
-40...+85 °C (-40... +185 °F)
Relative Humidity 5...95% non-condensing
Vibration Operating: 10... 500 Hz, 5 g, 0.015 in. max. peak-to-peak, 2 hours each axis
Relay Operation: 1.5 g
Shock, Operating 30 g; 3 pulses each direction, each axis
Relay Operation: 10 g
