10
Jul. 2007 AC-90
Parts List
fig.part1e
SAFETY PRECAUTIONS:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
NOTE: The parts marked # are new. (initial parts)
Due to one or more of the following reasons,
parts with parts code ******** cannot be supplied as service parts.
• Part supplied only as a component in a complete assembly
• Copyright does not permit the part to be supplied
• Part is sold commercially
The description "Q'TY" means a necessary number of the parts per one product.
CASING
SD000719 BADGE LOGO NET BOARD 1
# SD001005 FOOT D25XT18 4
# SD001004 CABINET ASSY 1
NOTE: ‘CABINET ASSY’ includes the following parts.
******** ACOUSTIC FOAM A 1
******** ACOUSTIC FOAM B 4
******** ACOUSTIC FOAM C 1
******** ACOUSTIC FOAM D 2
SD000079 CATCH BLK(73) 4
******** MINI BELT 0.2X90L BLACK 2
******** CR-based Rubber Sponge 105X21X5.0mm 2
SD000463 HANDLE HOLDER 2
SD000462 HANDLE PLATE 1
SD000461 HANDLE RUBBER 1
# SD001003 NET BOARD ASSY 1
NOTE: ‘NET BOARD ASSY’ includes the following parts.
******** CLOTH 1
# SD001006 STAND 1
17055020 STAND ADAPTOR 1
# SD001007 STAND HOLDER 2
CHASSIS
# SD001008 CHASSIS
22360705 CORD HOOK 2
SD000182 STAY 3
KNOB, BUTTON
SD000083 KNOB S 12
SD000082 PUSH BUTTON 7
SWITCH
SD000105 SLIDE SWITCH SSSF021500 1
03782367 SEESAW SWITCH JW-L11RKK 1
01454723 PUSH SWITCH ESB64620 1
SD000099 PUSH SWITCH ESB64619 6
JACK, EXT TERMINAL
00122123 XLR CONNECTER YKF52-5003N JK6, 9 2
13449643 JACK (PIN JACK 2P) WHT/
RED
YKC21-3091 JK5 1
13449169 6.5MM JACK YKB21-5078 JK2 1
13449146 6.5MM JACK YKB21-5012 (W/SW) JK1, 4, 7, 12, 400 5
13449145 6.5MM JACK YKB21-5010 JK13 1
13449252 6.5MM JACK YKB21-5006 (STEREO W/SW) JK11, 401 2
01901001 XLR CONNECTER NCJ9FI-H JK3 1
SPEAKER, BUZZER
# SD001001 SPEAKER FULL RANGE W0804-435A (8INCH) 2
# SD001002 SPEAKER TWEETER T08504-435A 2
To Next Page
