Oct. 2016 AE-10

Parts List

fig.-part1-e.eps

Note: The parts marked # are new. (initial parts) The description “Q’ty” means a necessary number of the parts per one product.

Due to one or more of the following reasons, parts with parts code ******** cannot be supplied

as service parts.

• Supply is prohibited due to copyright restrictions.

• It is carried in electronic data on the Roland web site.

• The part is made to order (at current market price).

• It can be replaced with an article on the market. (battery or etc.)

• It is a package or an accessory irrelevant to the function maintenance of the main body.

• A number of circuit boards are grouped together and supplied as a single circuit board (under a different part code).

• Reissuance is restricted.

• It is supplied as an assembled part

(under a different part code).

Safety Precautions:

The parts marked have

safety-related characteristics. Use

only listed parts for replacement.

CASING

# 5100052656 TOP CASE 1

# 5100053077 LCD COVER 1

# 5100052690 SENSOR COVER 1

# 5100052689 BATTERY COVER 1

# 5100052706 NECK 1

# 5100052657 BOTTOM CASE 1

KNOB, BUTTON

# 5100052693 KEY OCT A 2

# 5100052694 KEY OCT B 2

# 5100052670 KEY-B 1

# 5100052671 KEY-B FLAT 1

# 5100052678 KEY-C 1

# 5100052672 KEY-C SHARP 1

# 5100052674 KEY-C3 1

# 5100052677 KEY-E FLAT 1

# 5100052673 KEY-G SHARP 1

# 5100052679 KEY-HI 3

# 5100052675 KEY-TCTA 2

# 5100052676 KEY-TF 1

# 5100052698 KEYTOP 3P 1

# 5100052667 R-KEYTOP A 3

# 5100052668 R-KEYTOP B 3

# 5100052669 R-KEYTOP C 1

# 5100052666 S-KEYTOP A 1

# 5100052712 RUBBER CAP 1

# 5100052658 RUBBER SW A 1

# 5100052659 RUBBER SW B 1

# 5100052660 RUBBER SW C 1

# 5100052661 RUBBER SW D 1

# 5100052662 RUBBER SW E 1

# 5100052663 RUBBER SW F 1

# 5100052664 RUBBER SW G 1

# 5100052665 RUBBER SW H 1

# 5100053076 RUBBER SW I 1

# 5100052695 SHELL TOP A 3

# 5100052696 SHELL TOP B 3

# 5100052697 SHELL TOP C 1

# 5100052680 TP BASE 1

# 5100052682 TP KNOB 1

SWITCH

00230489 SLIDE SWITCH SSSF122400 1

JACK, EXT TERMINAL

13449252 6.5MM JACK YKB21-5006 (STEREO W/SW) 1

04452945 3.5MM JACK YKB21-5344N 1

13449717 ADAPTOR JACK HEC2392-01-150 1

5100047083 USB CONNECTOR U7F04D-B1NB 1

DISPLAY UNIT

5100030607 LCD C-55612GNFU-LW-AEN 1

SPEAKER, BUZZER

# 5100050096 SPEAKER BMS28-12B-08H6.3RW038LF 2
