Roland CAMM-1 Pro PNC- 1410 User Manual

24
3 Replacement of Main Parts
3
3-4 PINCH ROLLER ASSEMBLIES_FIXING
1
1
Leave the equal space at both ends of CUTTER
PROTECTION.
2
Make sure the CUTTER PROTECTION is not bumpy by
pushing it with your finger.
Tapered type is used for left and right PINCH ROLLERS.
Be careful when replacing them.
Flat type is used for the MIDDLE PINCH ROLLER one.
3-5 CUTTER PROTECTION_FIXING
CUTTERÅ@PROTECTION
PINCH ROLLER
MIDDLE PINCH ROLLER

Roland CAMM-1 Pro PNC- 1410 Specifications

General

Interface	RS-232C
Maximum Media Thickness	1.0 mm
Mechanical Resolution	0.0125 mm/step
Software Resolution	0.025 mm/step
Power Requirements	100 - 240 VAC, 50/60 Hz
Operating Temperature	5 to 40°C
Operating Humidity	35 to 80% RH (no condensation)
