Dec. 2017 E-X20, E-X20A

Exploded View Parts List

* When replacing No.10 RUBBER SWITCH 13P for other than the highest position (right end) of the keyboard, cut 1P to change 13P to 12P.

* When parts except above are necessary for repair, replace the product itself with a new one.

Accessories Parts List

No. Part Code Part Name Description Q'ty

1 17042123 ROTATE WHEEL ASSY 1

2 17042124 JACK BOARD ASSY 1

3 17042125 VOLUME BOARD ASSY 1

4 17042126 VOLUME KNOB 1

5 17042127 MAIN BOARD ASSY for E-X20 1

17042207 MAIN BOARD ASSY for E-X20A 1

6 17042128 ENCODER BOARD ASSY 1

7 17042129 ENCODER KNOB 1

8 17042130 FUNCTION BOARD ASSY 1

9 17042131 SPEAKER 2

10 17042132 RUBBER SWITCH 13P 5

11 17042133 KEYSCAN BOARD H+L WO/RUBBER SW 1

12 17042134 NATURAL KEY 3-KEY GROUP 5

13 17042135 NATURAL KEY 4-KEY GROUP 5

14 17042136 NATURAL KEY SINGLE 1

15 17042137 SHARP KEY 5

16 17042138 BATTERY COVER 1

Part Code Part Name Description Q'ty

17042139 MUSIC REST 1

17042140 OWNER'S MANUAL ENGLISH for E-X20 1

17042208 OWNER'S MANUAL ENGLISH for E-X20A 1

17042141 OWNER'S MANUAL CHINESE for E-X20 1

17042209 OWNER'S MANUAL CHINESE for E-X20A 1

17042341 AC ADAPTOR MU12AR120100-D1 (26) for 117VBL 1

17042142 AC ADAPTOR MU12AR120100-A1 (28) for 117VU/CS 1

17042143 AC ADAPTOR MU12AR120100-C5 (32) for 230VEU 1

17042144 AC ADAPTOR MU12AR120100-B3 (36) for 230VIN 1

17042145 AC ADAPTOR MU12AR120100-B2 (49) for 230VE 1

17042146 AC ADAPTOR MU12AR120100-A2 (65) for 220VCN 1
