FS-1-WL Connection
Guide
This explains how to use BLE MIDI to pair (connect)
the FS-1-WL to the AC-22LX over a wireless
connection.
* The Bluetooth Audio MIDI Dual Adaptor
(Model: BT-DUAL, sold separately) is needed
when wirelessly pairing the EV-1-WL with the
AC-22LX. See the Owner’s Manual for how to
attach the adaptor.
What is “BLE MIDI”?
“BLE MIDI” is the technology used to transmit and
receive MIDI messages wirelessly via Bluetooth®
LE standard.
This is ocially known as “MIDI over Bluetooth Low
Energy”.
