EXR-7
7
EXPLODED VIEW - BOTTOM
1
2
3
9
7
6
5
4
2
8
No.
Part No.
1
7775710000
2
3
J240910601
4
7775701000
5
22165134
6
7
22265242
8
9
K2358105
7775720000
K2418125
7775709000
Description
FLOPPY D.DRIVER JU-257A167P
BRASS BUSHING
RUBBER GUIDE BUSHING
PRESSURE RUBBER
76 KEY KEYBOARD TP/9S
BLACK VARN+CONDUCTIVE BOTTOM CBNT
LOUDSPEAKER MM.130 4OHM RIF.2313
VARN+SILK. KEYBOARD BLIND EXR-7
CPU PCB ASSY EXR-7
A
B
J2289212
J2289131
(SCREW)
SELF TAP. SCREW 3,5x16 TCTC PR BZ
SCREW 3,5X10 TC TC PR BRUN
A
A
A
A
B
