42
Saving Your Performance
Here’s how you can delete a previously saved song from
internal memory.
If you want to delete all songs from internal memory,
refer to “Deleting All Songs” (p. 43).
fig.SaveButtonz.eps_88
1.
Hold down the [Reverb] button and press the
[Transpose] button.
The display will indicate “Fnc,” and you’ll be in Function
mode.
fig.d-Fnc.eps_88
2.
Hold down the [Song] button and use the [-] [+]
buttons to make the display indicate “dEL.”
When you take your finger off the button, the following
message will appear and the [ ] button will flash.
fig.d-U01.eps_88
The number that appears in the display always refers to the
first stored User memory and may differ from the one shown
in the illustration.
3.
Use the [–] [+] buttons to select the song that you
want to delete.
Deleting the Song
4.
Press the [
] button.
The display will indicate “Sur,” and the [
] button and
[
] button will flash.
fig.d-Sur.eps_88
If you decide not to delete the song, press the [
]
button.
5.
Press the [
] button.
The selected song will be deleted.
fig.d-dEL.eps_88
Never turn off the power while “dEL” is blinking in the
display.
If the song you just deleted was the only one in the
F-110’s internal memory, the display will briefly show
the “non” message.
6.
Press the [Reverb] or [Transpose] button to leave
Function mode.
Deleting a Song
