INSTALLATION
Check that you have all of the supplied parts:
fig.05
Tapping Flat A13 x 16 mm
Tapping Pan A13 x 20 mm
Spring
LP spacer
Double-sided tape A
Double-sided tape B
x 1 (for installing the Contoroller)
x 2
(for installing the Divided Pickup)
x 2
(for installing the Divided Pickup)
x 6 (for installing the Contoroller)
x 3 (for installing the Contoroller)
x 4
(for installing the Divided Pickup)
Pickup cushion
Pickup Spacer A
Pickup Spacer B
Velcro fastener
x 2
(for installing the Divided Pickup)
x 5 (for adjusting the height of the
Divided Pickup)
x 10 (for adjusting the height of the
Divided Pickup)
x 1 (for adjusting the height of the
Divided Pickup)
Holder A
Holder B
Wing Nut
Spring Washer
Washer
x 1
(for attaching the Holder B)
x 1
(for attaching the Holder B)
x 1
(for attaching the Holder B)
Standard Guitar Cable
To Next Page
