9
Feb. 2010 ME-25
Parts List
fig.-part1-e.eps
Safety Precautions:
The parts marked have
safety-related characteristics. Use
only listed parts for replacement.
Note: The parts marked # are new. (initial parts) The description “Q’ty” means a necessary number of the parts per one product.
Due to one or more of the following reasons,
parts with parts code ******** cannot be supplied as service parts.
• Part supplied only as a component in a complete assembly
• Copyright does not permit the part to be supplied
• Part is sold commercially
CASING
# 5100011390 TOP COVER 1
# 5100011391 BOTTOM COVER 1
04560878 BATTERY COVER RTC #G2027602R0 1
CHASSIS
03561356 SHAFT STAY STAY 1
73455190 BATTERY CASE SET 1
# 5100011394 PEDAL HOLDER 1
# 5100011395 PEDAL PLATE 1
# 5100011396 JACK HOLDER 1
KNOB, BUTTON
03344934 R-KNOB (G2477122/75D522N0R0) 4
SWITCH
01780101 TACT SWITCH SKQKABD010 9
03344723 TACT SWITCH SKQKAKD010 3
JACK, EXT TERMINAL
02781101 USB CONNECTOR B TYPE FEMALE YKF45-0020N 1
03012689 3.5MM JACK HTJ-035-23DBS 1
03568167 6.5MM JACK HTJ-064-11D 1
04909467 6.5MM JACK(PHONES) HTJ-064-05A 1
# 5100003941 6.5MM JACK HTJ-064-11I (F3449118R0) 2
04908701 ADAPTOR JACK KM02018ABM1P 1
PWB ASSY
# 5100009941 MAIN SHEET ASSY 1
* This unit includes the following parts.
# ******** MAIN BOARD ASSY 1
# ******** EXP BOARD ASSY 1
DIODE
04788078 LED KP-1608PBC-A 1
5100006346 LED KP-1608SURC 6
# 5100001581 LED A-552SR-A B/W (F5029412R0) 7-segment LED 1
05015956 LED L-7104SRT (F5229820R0) lamp type (until B**1349) 2
5100006346 LED KP-1608SURC tip type (from B**1350) 2
POTENTIOMETER
01016167 11M/M ROTARY POTENTIOMETER RK11K1140AFG 10KX1 on Exp Board 1
5100001448 POTENTIOMETER (F3279802R0) RD901F-40-125F-B50K-00D 3
5100001452 POTENTIOMETER (F3229205R0) RD901F-40-125F-B50K-0BD 1
WIRING, CABLE
# 5100011956 WIRING 3P 1
To Next Page
