40
Apr. 2006 R-09
Circuit Diagram (BOTTOM BOARD)
fig.diagram-bottom
Messages
Messages in the display are shown below.
AGC Low
Cut
MICGAIN
H/L
MIC
TYPE
XLIMITER_BB
XLO_CUT_BB
XINPUT_HXL_BB
XCOND_MIC_BB
D
DDDD
SW8B
SSSS820101
22
21
23
SW9B
SSSS820101
22
21
23
SW10B
SSSS820101
22
21
23
SW7B
SSSS820101
22
21
23
CN5
06FLZ-RSM2-TB
1
2
3
4
5
6
1
2
3
4
5
6
SW7A
SSSS820101
12
11
13
SW8A
SSSS820101
12
11
13
SW9A
SSSS820101
12
11
13
SW10A
SSSS820101
12
11
13
R63
0
R62
0
R61
0
R60
0
Message Problem
Clock Initialized
The internal clock was initialized
because no power was available.
Battery Low
The remaining power of the inter-
nal battery is low.
The battery must be replaced. The
AC adaptor may also be used.
Improper Song
The song is in a file format that
cannot be used with the R-09.
Already Exists
There is a song or folder of the
same name.
Create the song or folder using a
different name.
Song Protected
The song is protected. Turn Write
protect OFF and then try again.
Name Too Long
The name is too long.
File System Err
The memory card has not been for-
matted.
Format the memory card on the R-
09.
SD Unformatted
The memory card is not formatted
or cannot be recognized.
Format the memory card on the R-
09.
SD Card Full
The memory card does not have
sufficient space available.
Copy the song to the PC and check
the memory card capacity.
SD Card Slow
The write to the memory card was
too slow.
Use a memory card that was tested
for the R-09.
The performance of the memory
card may have decreased because
of improper song organization on
the memory card, which was
caused by repeated saving and de-
leting. In this case, re-format the
memory card.
Message Problem
To Next Page
