Apr, 1998
SPD-20
CIRCUIT BOARD/基板図
For Nordic Countries
Apparatus containing
Lithium batteries
ADVARSEL!
Lithiumbatteri - Eksplosionsfare ved
fejlagtig håndtering.
Udskiftning må kun ske med batteri af
samme fabrikat og type.
Levér det brugte batteri tilbage til
leverandøren.
CAUTION!
Danger of explosion if battery is
incorrectly replaced.
Replace only with the same or
equivalent type recommended by
manufacture.
Discard used batteries according to the
manufacturer's instructions.
ADVARSEL!
Lithiumbatteri - Eksplosjonsfare.
Ved utskifting benyttes kun batteri som
anbefalt av apparatfabrikanten.
Brukt batteri returneres
apparatleverandøren.
VARNING!
Explosionsfara vid felaktigt batteribyte.
Använd samma batterityp eller en
ekvivalent typ som rekommenderas av
apparattillverkaren.
Kassera använt batteri enligt
fabrikantens instruktion.
VAROITUS!
Paristo voi räjähtää, jos se on
virheellisesti asennettu.
Vaihda paristo ainoastaan
laitevalmistajan suosittelemaan
tyyppiin. Hävitä käytetty paristo
valmistajan ohjeiden mukaisesti.
VOLUME BOARD ASS'Y
ASSY 71120167
MAIN BOARD ASS'Y
ASSY 71120156
PANEL BOARD ASS'Y
ASSY 71120145
