23
Overall Settings (SETUP)
SD card folder structure
REC folder
Recorded data that was exported
is saved here.
IMPORT folder
If there are audio les that you
want to import as user samples,
save them in this folder.
TD-17 folder
Roland folder
This unit’s backup data is saved
here.
Backup folder
Backup data is saved
here.
Kit folder
Kit backup data is saved
here.
When saving audio les on an SD card
Audio les can be played back from the root level of the
SD card drive (p. 9).
* Make sure that no single le is larger than 2 GB.
Audio les that can be played by this unit
WAV MP3
Format
(extension)
WAV (.wav) MP3 (.mp3)
Sampling
frequency
44.1 kHz 44.1 kHz
Bit rate 16, 24-bit 64 kbps–320 kbps
* File names that contain more than 14 characters
are not shown correctly. Files using double-byte
characters are also not supported.
Making the Power Automatically Turn o
After a Time (AUTO OFF)
The power to this unit will be turned o automatically after
a predetermined amount of time has passed since it was
last used for playing music, or its buttons or controls were
operated (AUTO OFF function).
If you do not want the power to be turned o automatically,
disengage the AUTO OFF function.
* To restore power, turn the power on again.
1. Press the [SETUP] button.
2. Use the dial to select the “AUTO OFF,” and
press the [ENTER] button.
The AUTO OFF screen appears.
3. Turn the dial to set the AUTO OFF function.
Value Explanation
OFF
The power does not turn o
automatically.
10 MINS
The power turns o automatically
when no pad has been struck or
any operation performed for the
specied time (10 minutes, 30
minutes, 4 hours).
30 MINS
4 HOURS
4. Press the [DRUM KIT] button to return to the
KIT screen.
MEMO
If the AUTO OFF function is set, a countdown message is
shown before the power turns o.
The timing at which the countdown message appears
depends on the AUTO OFF setting.
