RuggedCom RuggedSwitch RSG2100 User Manual

Technical Specifications
3.7 Operating Environment
Parameter Range Comments
Ambient Operating
Temperature
-40 to 85C
Ambient Temperature as
measured from a 30cm
radius surrounding the
center of the enclosure.
Ambient Relative Humidity 5% to 95% Non-condensing
Ambient Storage
Temperature
-40 to 85C
3.8 Mechanical Specifications
Parameter Value Comments
Dimensions 18.29 x 10.17 x 1.74 inches
(464,57) x (258,32) x (44,20)
mm
(Length x Width x
Height)
with mounting brackets
installed
Weight 10 lb (4.5 Kg)
Enclosure 18 AWG galvanized steel
RuggedCom
®
34 RuggedSwitch
®
RSG2100

RuggedCom RuggedSwitch RSG2100 Specifications

General

Operating Temperature	-40°C to +85°C (-40°F to +185°F)
Power Supply	88-300 VAC/VDC
Mounting	DIN rail or panel mount
Management	Web-based, CLI, SNMP
Protection	Surge protection
Dimensions	135 x 196 x 119 mm
Standards Compliance	IEC 61850-3, IEEE 1613, EN 50121-4
Weight	0.8 kg (1.76 lb)
