Ruijie Reyee RG-ES100 Series User Manual

Hardware Installation and Reference Guide Product Overview
11
1.4 RG-ES118S-LP
Technical Specifications
Model
RG-ES118S-LP
Ports
Sixteen 10/100Base-TX auto-sensing Ethernet ports (auto MDI/MDIX), and PoE/PoE+ support
Two 1000Base-X SFP combo ports
Power Supply
 AC input
Rated voltage range: 100 V AC to 240 V AC
Maximum voltage range: 90 V AC to 264 V AC
Frequency: 50/60 Hz
Rated current: 2.5 A
EEE
Ports 1–16: supported
Ports 17–18: not supported
PoE
PoE/PoE+ support
Ports 1 to 16 support PoE/PoE+ with the maximum power output of 30 W per port. Ports 17-18
do not support PoE or PoE+.
The overall maximum output power of PoE/PoE+ is 120 W.
Power
Consumption
Less than 13 W with no PoE load
Less than 148 W with PoE full load
Operating
Temperature
0°C to 45°C (32°F to 113°F)
Storage
Temperature
-40°C to +70°C (-40°F to +158°F)
Operating Humidity
10% to 90% RH
Storage Humidity
5% to 95% RH
Port Mode
Switchover in three modes:
1. Flow Control On
2. Flow Control Off
3. Port Isolation
When port isolation is enabled, ports 1-16 are isolated from each other, but can communicate
with ports 17 and 18.
Fan
Not supported
Temperature
Warning
Not supported
Accessing Optical
Module Information
Not supported
Certification
CE
Earth Leakage
Current
≤ 1.5 mA
Dimensions
(W x D x H)
440 mm x 208 mm x 44 mm (17.32 in. x 8.19 in. x 1.73 in.)
Weight
3.40 kg (7.50 lbs)
