Ruijie Reyee RG-RAP6202(G) User Manual

Hardware Installation Guide and Reference Product Overview
7
LED
Status
Meaning
A long blink and three
short blinks
Other faults occur.
Solid on
The device is working properly without alarm.
Off
The device is powered off.
LAN 1(Green)
Blinking
The port is up and data is transmitted.
Solid on
The port is up and no data is transmitted.
Off
The port is down.
LAN 2(Green)
Blinking
The port is up and data is transmitted.
Solid on
The port is up and no data is transmitted.
Off
The port is down.
1.3 Technical Specifications
Table 1-4 Technical Specifications of RG-RAP6202(G)
Max Transmission Rate
Built-in antenna mode: 1267Mbps (867Mbps@5GHz ; 400Mbps@2.4GHz)
Operating Frequency
802.11b/g/n: 2.4 GHz to 2.4835 GHz
802.11a/n/ac: 5.150 GHz to 5.350 GHz, 5.47 GHz to 5.725 GHz, 5.725 GHz to
5.850 GHz
(Country-Specific)
Transmit Power
2.4 GHz: ≤ 26 dBm(adjustable)
5 GHz: ≤ 27 dBm(adjustable)
Antenna Type
Built-in omnidirectional antennas
Antenna Gain
2.4 GHz: 3dBi
5 GHz: 4dBi
Beam Width
2.4 GHz E: 30°; H: 360°
5 GHz E: 30°; H: 360°
Ports
One 10/100/1000BASE-T Ethernet uplink port supports 802.3af/ 802.3at PoE
input.
One 10/100/1000 Base-T Ethernet port
FAT/FIT Mode Switchover
Not Supported
Power Supply
IEEE 802.af/at PoE
DC power port: 12 V/1.5 A
