Ruijie RG-AP130(L) User Manual

·
Hardware Installation and Reference Guide System Debugging
4 System Debugging
4.1 Setting up a Debugging Environment
Use PoE to power the AP.
PoE power supply
To use a PoE device, make sure the peer end supports the IEEE 802.3af PoE standard. Then, connect the Ethernet cable
to the uplink port (WAN) on the AP.
Figure 4-1 Connect the Ethernet Cable to the UpLNK Port
DC power adapter power supply
DC power adapter supply is not supported on RG-AP130(L).
4.1.1 Powering Up the AP
4.1.1.1 Checking before power-up
 Verify that the input voltage matches the specification of the AP.

Ruijie RG-AP130(L) Specifications

General

Brand	Ruijie
Model	RG-AP130(L)
Category	Wireless Access Point
Language	English
