Drilling capacity
in wood25 mm30 mm
in steel10 mm 13 mm
in masonry13 mm13 mm
Input550 W750 W
No load speed 0 - 2,700 min
-1
0 - 2,800 min
-1
Blows per minute 0 - 43,200 min
-1
0 - 44,800 min
-1
A. Trigger Switch
B.Forward / Reverse Lever
C.Keyless Chuck
D.Variable Speed Control
E.Lock - on Button
F.Impact Drilling Mode Selector
G.Depth Gauge
H.Auxiliary Handle
I.Bit
J.Air Vents
K
.PowerLight
TM
L.Bit Storage (EID750REN)
Auxiliary handle, Depth Gauge, Drill Bit.
Use only for the purposes listed below:
Drilling wood, materials and resin boards.
Drilling concrete (impact drilling only).
Drill metal: steel, brass, aluminum sheets, stainless
steel & pipe.
Noise (sound pressure level) in the workplace can
exceed 85 dB (A). in this case, sound insulation and hearing
protection measures must be taken by the operator.
This tool is started and stopped by squeezing
and releasing the trigger switch (A).
The speed can be adjusted in either gear by
controlling the force applied to the trigger.
The maximum speed of the drill may be set at different
speeds by adjusting the variable speed control (D).
For continuous operation, press the lock- on button (E)
while squeezing the trigge
r. Squeeze the trigger again
to release the lock.
To change the direction of rotation, stop the tool and
push the forward / reverse level (B).
When the forward button is pushed in, the bit rotates
clockwise when viewed from the handle end of the tool.
When the reverse button is pushed in, the bit rotates
counterclockwise.
SPINDLE LOCK (EID750REN)
For easy changing of the drill bit this drill is equipped with
an automatic spindle lock (M) which holds the spindle
stationary when loosening and tightening the chuck.
MOUNTING AND REMOVING THE BIT (Fig. 4a &4b)
Insert the drill bit (I) into the chuck (C) as far as the plain
part of its shank will go.
Tighten the chuck securely by rotate the chuck head
in a clockwise direction.
The bit can be removed by rotate the chuck in a
counterclockwise direction.
CHANGING BETWEEN DRILLING AND IMPACT
DRILLING MODE (Fig. 5)
The drilling mode shift knob (F) for changing between
the drilling mode and impact drilling mode is positioned
on the top of the tool.
DRILLING MODE:Shift the button and show the" "
symbol for rotation without impact action.
IMPACT DRILLING MODE:Shift the button and show the "
" " symbol for impact drilling.
2
M.Spindle Lock Button (EID750REN)
CHANGING THE ROTATION DIRECTION (Fig.2)
To insert a drill bit (I), press the spindle lock button
(M) with one hand and use your other hand to rotate
the chuck anti-clockwise. Rotate it sufficently for
the chuck to open far enough to accept the bit
or accessory.
Fully insert the bit accessory into the chuck and
tighten securely by rotating the chuck clockwise
with one hand whilst holding the spindle lock
button pressed with the other hand.
Repeat 2nd point to remove the bit.
NOTE: Always be sure the spindle lock button is
released and the spindle lock is disengaged before
turning the drill ON.
N.Bubble Level (EID750REN)
