NEVER COVER THE AIR VENTS (J) SINCE THEYMUST
ALWAYS BE OPEN FOR PROPER MOTOR COOLING.
To prevent ugly splits around the drill hole on the reverse
side of the workpiece, put a piece of scrap timber under
the work piece.
Metals such as steel brass, aluminum sheets, stainless
steel and pipe may also be drilled. Mark the point to be
drilled with a nail or punch.
Do not use impact mode on these materials.
Stone and masonry are generally drilled in the impact
drilling mode.
When drilling in delicate materials such as wall tiles,
it is essential to start with ordinary drilling and once the
tile is pierced, to continue with impact drilling.
In deep bore holes the drill bit should be pulled out
occasionally in order to remove the debris from the
drill and hole.
The auxiliary handle also contains a compartment to
store dill bits. To access this compartment unscrew the
end cap below the yellow trim on the handle in an
anticlockwise direction.
After use, check the tool to make sure that it is in good
condition. It is recommended that you take this tool to
a RYOBI Authorized Service Centre for a thorough
cleaning and lubrication at least once a year.
DO NOT MAKE ANYADJUSTMENTS WHILE
THE MOTOR IS IN MOTION.
ALWAYS DISCONNECT THE POWER CORD FROM
THE POWER SUPPLYBEFORE CHANGING
REMOVABLEOR CONSUMABLE PARTS (BLADE,
BIT, SANDING PAPER ETC.), LUBRICATING OR
WORKING ON THE UNIT.
WARNING
To ensure safety and reliability, all repairs should
be performed by an AUTHORIZED SERVICE
CENTRE or other QUALIFIED SERVICE
ORGANIZATION.
3
AUXILIARY HANDLE (Fig. 6)
Auxiliary handle.
The auxiliary handle (I) can be rotated 360º.
Loosen the handle grip by turning in an anticlockwise drection
and tighten it at an easy to use position by turning the grip
in a clockwise direction.
AUXILIARY SIDE HANLDE BIT HOLDER (EID750REN)
The auxiliary side handle on this impact drill is equipped
with a removable base cap which has the ability to hold up
to 5 drill bits. To remove the bit holder screw the cap in an
anticlockwise direction. Remove bits but pulling them up
out of the holder. To replace the bit holder screw cap in a
BIT STORAGE (EID-750REN) (Fig. 7)
PowerLight
TM
This tool feautres a PowerLight
TM
(K) which illuminates as soon
as the tool is connected to the power supply. This warns the
user that the tool is connected
to live power and will operate
when the switch is pressed.
If the supply cord is damaged, it shall be replaced by
the manufacturer or its service agent or similar qualified
person in order to avoid a hazard
SAVE THESE INSTRUCTIONS FOR FUTURE
REFERENCE.
