Ryobi OLT1832 User Manual

15
OPERATION
ADJUSTING THE LINE LENGTH
1. Press the latches on the battery pack to
remove the battery pack.
2. Loosen the screw on the cut-off blade. Rotate
the cut-off blade.
NOTE: The cutting width of the line trimmer can
be adjusted according to preference. A cutting
width of 30 cm gets the job done faster but results
in a lesser runtime.
3. Install the screw on the cut-off blade. Tighten
the screw to secure the cut-off blade.
1
2
3
25 cm
30 cm
30 cm
25 cm
1
2
30 cm
25 cm
2
3
1
2
1

Ryobi OLT1832 Specifications

General

Line Diameter	1.6 mm
Adjustable Handle	Yes
Telescopic Shaft	Yes
Line Feed System	Automatic
Power Source	18V
Cutting Width	25-30 cm
