LOCK-OFF
BUTTON
FEATURES
Fig. 1
PRODUCT SPECIFICATIONS
Motor ..................................................................... 18 V DC
Blade Diameter ...................................................... 5-1/2 in.
Blade Arbor ...............................................................3/8 in.
Cutting Depth at 0° .............................................. 1-9/16 in.
BLADE
UPPER
BLADE
GUARD
LOWER BLADE
GUARD
SWITCH
TRIGGER
LOWER BLADE
GUARD HANDLE
BEVEL
ADJUSTMENT
KNOB
HANDLE
LASER
GUIDE
LASER GUIDE
SWITCH
Cutting Depth at 45° .............................................. 1-1/8 in.
No Load Speed .....................................4,200 r/min. (RPM)
Laser Guide ........................Class IIIa, <5mW max, 650 nm
BLADE WRENCH
(5 mm HEX KEY)
DEPTH
ADJUSTMENT KNOB
BLADE WRENCH
STORAGE AREA
OPTIONAL RIP
GUIDE SCREW
(WING SCREW)
WIDTH OF CUT
SCALE

Ryobi P506 Specifications

General

Brand	Ryobi
Model	P506
Category	Saw
Language	English
