ENGLISH
TIONS
Vibration level idling
Front Handle 3.7 m/s
2
2.7 m/s
2
11.0 m/s
2
8.1 m/s
2
Rear Handle
Vibration level racing
Front Handle
Rear Handle .
Sound pressure level
(in accordance with EN ISO 11806:
1997, ISO 7917:1987) 101 LpA (dBA)
Sound power level (in accordance
with ISO 10884) 108 LwA (dBpA)
DESCRIPTION
1. Starter Grip
2. Front Handle
3. Shaft
4. Throttle Trigger
5. Safety Guard
6. Cutting Line
7. Bump Head
8. On / Off Switch
9.
Throttle Control & Rear Handle
10. Muffler Guard
11. Choke Lever
12. Bolt
13. Bracket
14. Wing Nut
15. Lock Washer
32. Bump Knob
33. Slots
34. Eyelets
35. Drive Connector
36. Spring
37. First Line
38. Anchor Hole
39. Arrows On Spool
45.
Idle Speed Screw
40. Second Line
41. Dangerous Cutting Area
42. Fuel Cap
43. Filter
44. Air Filter Cover
The trimmer attachment (55) connects to the power head
by means of a coupler (19) device.
Loosen the knob (17) on the coupler of the power
head shaft (54) and remove the end cap (23) from
the attachment.
Push in the button (60) located on the trimmer attachment
shaft. Align the button with the guide recess (57) on
the power head coupler and slide the two shafts together.
Rotate the trimmer attachment shaft until the button
locks into the positioning hole (58).
NOTE: If the button does not release completely in the
positioning hole, the shafts are not locked into place.
Slightly rotate from side to side until the button is locked
into place.
Tighten the knob securely.
WARNING
Be certain the knob is fully tightened before
operating equipment; check it periodically for
tightness during use to avoid serious injury.
REMOVING THE ATTACHMENT FROM THE
POWER HEAD
For removing or changing the attachment:
Loosen the knob.
Push in the button and twist the shafts to remove and
separate ends.
SPECIFICATIONS
Weight
Without fuel and bump head 4.07 Kg
Without fuel, w/bump head 5.09 Kg
Fuel tank volume 425 cm
3
Cutting swath 432 mm
Engine displacement 30 cc
Maximum engine performance
(in accordance with ISO 8893) 0.78 kW
Maximum rotational frequency
of the spindle
9,000/min
-1
Engine Speed (rotational frequency)
at recommended max.
spindle rotational frequency 12,500/min
-1
Engine speed (rotational frequency)
at idle 2800-3200/min
-1
Fuel consumption (in accordance with ISO 8893) at max.
engine performance
0.52 kg/h
Specific fuel consumption (in accordance with ISO 8893)
at max. engine performance 0.47 kg/h
16. Flat Washer
17. Knob
18. Rear Housing
23.
Hanger
24.
Best Cutting Area
25.
Direction Of Rotation
26.
Screw
27.
Primer Bulb
28.
Torx Wrench
31. Choke Position
22. Latch
47. Safety Button
48. Nuts
49. Handle Base
19. Coupler
20.
Bent End Of Muffler Guard
21.
Opening In Rear Housing
55. Trimmer Attachment
56. Spacer
57. Guide Recess
58. Positioning Hole
59. Hole
60. Button
61. Cut Off Blade
51.
"L" Lo Needle
52.
"H" High Needle
54.
Trimmer Shaft
50. Spool
ASSEMBLY
ATTACHING THE POWER HEAD TO THE
TRIMMER ATTACHMENT (Fig. 2)
WARNING
Never attach or adjust any attachment while
power head is running. Failure to stop the engine
may cause serious personal injury.
29.
Run Position
30.
Half Choke Position
- 2 -
