Ryobi RLM46160S User Manual

User Manual
11
PRODUCT SPECIFICATIONS
Engine displacement 161cc OHV
Type 4 stroke air cooled engine
No-load speed of cutting
means
2800 min
-1
Fuel consumption at Max.
Engine performance
1.1 kg/h
Specic fuel consumption at
Max. Engine performance
395 g/kW.h
Cutting width 46 cm
Self-propelled speed 1.0 m/s
2
Cutting height adjustment 7 positions, 25 mm - 75 mm
Wheel size (Front/ Rear) 17.8 cm (7 in.) /
20.3 cm (8 in.)
Fuel tank capacity 1300 ml (+/-50 ml)
Fuel type Unleaded fuel (91 or higher)
Oil type SAE 10W-30 API-SJ or higher
weight oil
Oil tank capacity 350 ml (+/-50 ml)
Net weight 31 kg
Grass catcher capacity 55 L
Disc bolt, blade bolt and blade
lock nut torque
35~45 Nm
Engine mounting bolt torque 20~25 Nm
Vibration Level (in accordance with Annex G of EN ISO 5395-
1:2013)
Right Handle 2.37 m/s
2
Left Handle 2.04 m/s
2
Uncertainty of Measurement 1.5 m/s
2
Declared vibration value 4.0 m/s
2
Noise emission level (in accordance with Annex F of EN ISO
3744:2010)
The guaranteed sound
pressure level LpA
79.0 dB(A)
The guaranteed sound power
level LwA
100.0 dB(A)
Uncertainty of Measurement 1.0 dB
Replacement part
Blade 099923021001
Rear drive wheel 099923022075

Ryobi RLM46160S Specifications

General

Type	Walk behind lawn mower
Noise level	96 dB
Cutting width	460 mm
Grass catcher	Yes
Product color	Black, Green, White
Cutting system	Rotary blades
Number of wheels	4 wheel(s)
Rotational speed	2800 RPM
Maximum lawn area	- m²
Engine displacement	160 cm³
Minimum cutting height	- mm
Grass collecting volume	55 L
Number of height positions	7
Engine power	3800 W
Power source	Gasoline
