7
Know your product
KNOW YOUR PRODUCT
12
13
14
2
3
1
7
456
8
9
10
11
1. Rear handle
2. Lock-out trigger
3. Variable speed trigger
4. Battery latch button
5. Battery pack
6. Charger
7. Lower shaft
8. Line cut-off blade
9. Lower housing
10. Bump knob
11. Inner spool
12. Cutting line
13. Front handle
14. Speed selector
