3.4 Datasheet
Suntrio Plus 12K/15K/17K/20K/25K
Type
Suntrio
Plus 12K
Suntrio
Plus 15K
Suntrio
Plus 17K
Suntrio
Plus 20K
Suntrio
Plus 25K
Input (DC)
Max. PV ArrayPower [Wp]@STC
1
18000 22500 25500 26000 37500
Max. DC Voltage [V]
1000
MPPT Voltage Range [V]
180-900
Nominal DC Voltage [V]
600
Start Voltage[V]
200
Min. DC Voltage[V]
180
Max. DC Input Current PV1 / PV2
[A]
22/11 22/22 22/22 22/22 22/22/22
Number of MPPT
2
3
Number of DC Connection Sets per
MPPT
2/1 2/2 2/2 2/2 2/2/2
DC Switch
Integrated
Output (AC)
Rated AC Power [W]
(@230V,50Hz)
12000 15000 17000 20000
25000
2
/2500
0
Max. AC Power [VA]
13200 16500 18700 22000
25000/2750
0
Rated AC Current[A]
17.4 21.7 25.8 29.0 37.9
Max. AC Current [A]
20.0 25.0 28.3 33.0 42.0
Nominal AC voltage/ range
3/N/PE, 220/380V,230/400V,240/415V;180V-280V/312V-485V
Grid frequency/ range
50Hz,60Hz /44Hz-55Hz,54Hz-65Hz
Power factor,adjustable
0.8 leading~0.8lagging
Total Harmonic Distortion (THDi)
< 3% (at nominal power)
Feed-in Grid
3L+N+PE
Efficiency
Max. Efficiency
98.3% 98.4% 98.5% 98.5% 98.6%
Euro Efficiency (at 600Vdc)
98.0% 98.1% 98.2% 98.2% 98.4%
MPPT Accuracy
>99.5%
Protection
Internal Over-voltage Protection
Integrated
DC Insulation Monitoring
Integrated
DCI Monitoring
Integrated
GFCI Monitoring
Integrated

SAJ Suntrio Plus Series Specifications

General

Brand	SAJ
Model	Suntrio Plus Series
Category	Inverter
Language	English
