OPERATION
The ST620 is configured and adjusted by the use of an
innovative and stylish Touch Ring, and two touch sensitive
buttons. The Touch Ring surrounds the programmable
thermostat display, and is operated very easily by moving
your finger around the ring.
The backlit Liquid Crystal Display (LCD) gives a highly visible,
easily readable indication of the thermostat status.
ACCESSING THE MENUS
The Arrow key is not active when the ST620 is in NORMAL mode. To access
the Menu screens, press the OK key twice. The first menu displayed is the
PROGRAMME menu:
Use the Touch Ring to scroll through
the Menus, and press the OK key to
select the menu you want to use:
You can scroll through the menus in
either direction (forwards or
backwards) depending on the
direction you move your finger
around the Touch Ring. The menus
are displayed in the order shown in
the picture above.
Pressing and holding the Arrow key for 2 seconds will return the ST620 to NORMAL mode. The
programmable thermostat will also return to NORMAL mode after 10 seconds if no Key is pressed or
if no movement is detected on the Touch Ring.
ST620 INSTRUCTION MANUAL10
