MXS Series Power Amplifiers
Model MXS3000 MXS3500
Rated Output Power
Stereo both channel driven
8 ohms 950W 1100W
4 ohms 1550W 1900W
2 ohms 1850W 2700W
Bridged mono
8 ohms 3100W 3700W
4 ohms 4600W 5400W
Signal to Noise Ratio (20Hz-20k) >103dB
Distortion (SMPTE-IM) 0.02%
Input sensitivity @8ohms Voltage Gain 0dBu
Voltage Gain @ 8 ohm 38dB 39dB
Output Circuitry Class H
Current Consumption (115VAC/230VAC)
@1/8 rated power 4ohms 670W 850W
@1/3 rated power 4ohms 1400W 1700W
@ rated power 4ohms, max. 2600W 3300W
Distortion (typical @4 ohms)
20Hz-20kHz,10dB below rated power 0.003%
1kHz,rated power 0.007%
Frequency Response @8ohms 1Watt 20Hz to 20KHz +0/-0.2dB
4Hz to 50kHz ±3dB
Damping Factor (400Hz) >300
Input Impedance Balanced 20K/Unbalanced 10K
Input Clipping 0dB
Cooling Dual continuously variable speed fan;
Back-to-Front air flow
Connectors (each channel)
Inputs 3-pin XLR and ¼” TRS, balanced
Outputs Binding post and Speakon®
Indicators Signal, -20dB, -10dB, Limit, Thermal
Protection
Amplifier protection: Thermal,Short,DC
output, mismatched loads
Amplifier protection: On/off muting and
Delay, Locked the power amplifiers
Dimensions (LxWxH) 19” x 14.7” x 3.5”
482mm x 375mm x 88mm
Net Weight 21.6lb / 9.8kg
Specications
