2-2 Samsung Electronics
2-2 Product Specifications
Model
Item
AQV09VBC AQV12VBC
Indoor Unit Outdoor Unit Indoor Unit Outdoor Unit
Type Wall-mounted Wall-mounted
Performance
Capacity
Cooling
kW
(
Low / Std / Max)
0.99 / 2.50 / 3.20 0.99 / 3.50 / 4.00
Heating 0.99 / 3.50 / 4.50 0.99 /4.00 / 5.20
Running Frequency
Cooling
Hz
(
Low / Std / Max)
20 / 46 / 61 20 / 71 / 81
Heating 20 / 66 / 85 20 / 77 / 95
Dehumidifying ℓ/h 1.4 1.6
Air Volume
Cooling
㎥/min
(H/M/L)
8.6/8.1/7.6 28 8.9/8.3/7.6 28
Heating 9.5/8.9/8.3 27 10/9.4/8.8 27
Noise
Cooling
dB
(
H/L)
41/25 51 43/25 53
Heating 41/25 51 43/25 53
Energy Efficiency
Ratio
Cooling
W/W
(
Std)
4.10 3.40
Heating 4.10 3.64
Power ph-V-Hz 1-220/240-50 1-220/240-50
Power
Power Consumtion
Cooling
W
(
Low / Std / Max)
240 / 610 / 840 240 / 1030 / 1200
Heating 200 / 853 / 1450 200 / 1100 / 1600
Operating Current
Cooling
A
(
Low / Std / Max)
1.5 / 3.0 / 4.0 1.5 / 4.8 / 5.8
Heating 1.4 / 4.5 / 6.0 1.4 / 5.2 / 7.0
Power Factor
Cooling
%
(
Low / Std / Max)
70 / 85 / 90 70 / 90 / 90
Heating 70 / 85 / 90 70 / 90 / 90
Power Cord
Length m 2 2
Number of Core Wire 3 3
Capacity A 1
0 10
Size
Outer Dimension Width x Height x Depth mm 825 X 285 X 189 790 X 548 X 285 825 X 285 X 189 790 X 548 X 285
Weight (Net) kg 9.0 32.6 9.0 32.6
Refrigerant Pipe
Liquid mm x L(m) Φ6.35 x 5 Φ6.35 x 5
Gas mm x L(m) Φ9.52 x 5 Φ9.52 x 5
Drain Hose D x L(mm) Φ18 x 550 Φ18 x 550
Compressor
Type Rotary, G4C090LUDER Rotary, G4C090LUDER
Motor
Type Hermetic Hermetic
Rated Output 853W 853W
Oil Type FREOLα68ES-T FREOLα68ES-T
Blower
Type Cross-flow Propeller Cross-flow Propeller
Motor
Type Resin / Steel, AC Resin / Steel, DC Resin / Steel, AC Resin / Steel, DC
Rated Output W 2
7 25 27 25
Heat Exchanger 2 Row 14 Step 1 Row 24 Step 2 Row 14 Step 1 Row 24 Step
Refrigerant Control Unit EEV EEV
Freezer Oil Capacity cc 320 320
Refrigerant to Change (R410A) g 9
00 900
Protection Device (OLP) None None
Cooling Test Condition Indoor Unit : DB27
°C WB 19 °C Outdoor Unit : DB35 °C WB 24 °C
Heating Test Condition Indoor Unit : DB20 °C WB 15 °C Outdoor Unit : DB7 °C WB 6 °C
Operation conditon range
cooling
indoor 16
°C ~ 32 °C 16 °C ~ 32 °C
Outdoor -10 °C ~ 43 °C -10 °C ~ 43 °C
heating
indoor -15
°C ~ 30 °C -15 °C ~ 30 °C
Outdoor -15 °C ~ 24 °C -15 °C ~ 24 °C
