Samsung DVD-D530 User Manual

12
Note :
- When play a disc that has MPEG Audio and you have Bitstream selected in the Audio Options
menu, the Digital Audio jack may not output audio
- There is no analogue audio output when you play a sound disc.
- Even when PCM Down sampling is Off
 •Somediscswillonlyoutputdownsampledaudiothroughthedigitaloutputs.
HDMI (Only DVD-D530)
- If your TV is not compatible with compressed multi-channel formats (Dolby Digital, MPEG),
you should set Digital Audio to PCM.
- If your TV is not compatible with LPCM sampling rates over 48kHz, you should set PCM
Down sampling to On.
Manufactured under licence from Dolby Laboratories. “Dolby” and the double-D symbol are trade-
marks of Dolby Laboratories.
Setting Up the Language Features
If you set the player menu, disc menu, audio and subtitle language in advance, they will come up
automatically every time you watch a movie.
1. With the unit in Stop mode, press the MENU button. Press the √/® buttons to select
SETTINGS, then press the ENTER button.
2. Press the π/† buttons to select LANGUAGE, then press the ® or ENTER button.
3. Press the π/† buttons to select the desired language, then press the ® or ENTER button.
Note
- The language is selected and the screen returns to Language Setup menu.
- To make the setup menu disappear, press the MENU button.
- If the selected language is not recorded on the disc, the original pre-recorded language is selected.
- Select “Original” if you want the defaultsoundtrack language to be the original language the disc
is recorded in.
- Select “Automatic” if you want the subtitle language to be the same as the language selected as
the audio language.
- Some discs may not contain the language you select as your initial language; in that case the
disc will use its original language setting.
Setting Up the System Options
1. With the unit in Stop mode, press the MENU button. Press the √/® buttons to select
SETTINGS, then press the ENTER button.
2. Press the π/† buttons to select SYSTEM, then press the ® or ENTER button.
3. Press the π/† buttons to select the desired item, then press the ® or ENTER button.
Setting Up the Anynet+(HDMI-CEC) (Only DVD-D530)
Anynet+isafunctionthatcanbeusedtooperatetheunitusingaSamsungTVremotecontrol,
by connecting the DVD D530 to a SAMSUNG TV using a HDMI Cable. (This is only available with
SAMSUNGTVsthatsupportAnynet+.
Select On when you connect the DVD D530withSamsungTVthatsupportAnynet+.
1. With the unit in Stop mode, press the MENU button. Press the √/® buttons to select
SETTINGS, then press the ENTER button.
2. Press the π/† buttons to select SYSTEM, then press the ® or ENTER button.
3. Press the π/† buttons to select ANYNET+ (HDMI-CEC), then press the ® or ENTER button.
4. SettheAnynet+(HDMI-CEC)to“On”onyourDVDPlayer,thenpresstheENTER button.
5. SettheAnynet+functionatyourTV.(SeetheTVinstructionmanualformoreinformation.).
Note
•BypressingthePLAY button of the unit while watching TV, the TV screen will change to the play
screen.
•IfyouplayaDVDwhentheTVpowerisoff,theTVwillpowerOn.
•IfyouturntheTVoff,theDVDPlayerwillpoweroffautomatically.
•IfyouchangetheHDMItoothersources(Composite,Component,...etc)inTVwhileplayingthe
DVD disc, the DVD Player will stop playing.
Note
• This option can be changed only when TV support BD Wise.
• Consult your TV User’s Manual to find out if your TV supports Progressive Scan. If
Progressive Scan is supported, follow the TV User’s Manual regarding Progressive Scan set-
tings in the TV’s menu system.
• If Video Output is set incorrectly, the screen may be blocked.
• The resolutions available for HDMI output depend on the connected TV or projector. For
details, see the user’s manual of your TV or projector.
• When the resolution is changed during playback, it may take a few seconds for a normal
image to appear.
• If you set the HDMI output resolution 720p,1080p or 1080i, HDMI output provides better pic-
ture quality.
• It is recommended to set the "BD Wise" to "Off" In case of playback JPEG image file bigger
than 720 X 480 pixel size.
Audio Options allows you to setup the audio device and sound status settings depending on the
audio system in use.
1. With the unit in Stop mode, press the MENU button. Press the √/® buttons to select
SETTINGS, then press the ENTER button.
2. Press the π/† buttons to select AUDIO, then press the ® or ENTER button.
3. Press the π/† buttons to select the desired item, then press the ® or ENTER button.
Setting Up the Audio Options

Samsung DVD-D530 Specifications

General

Audio formats supported	MP3, WMA
Image formats supported	JPG
Video formats supported	DivX
Device type	DVD player
Product color	Black
Disc types supported	CD, CD-R, CD-RW, DVD, DVD+R, DVD+RW, DVD-R, DVD-RW
Number of optical discs	1 discs
Composite video out	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power consumption (typical)	6 W
Dimensions (WxDxH)	360 x 207 x 42 mm

Weight and Dimensions

Weight	1260 g
