Samsung ES80 User Manual

Extended functions 32
Shooting modes
Recording a video
Record videos of up to 2 hours in length.
The recorded video is saved as an MJPEG file.
Memory cards with slow writing speeds will not support high-resolution
videos and high-speed videos. To record high-resolution or high-speed
videos, use memory cards with faster writing speeds (p. 36).
1
In Shooting mode, press [ ].
2
Select Movie.
3
Press [ ].
4
Select Movie → Frame Rate → a frame rate (the
number of frames per second).
• As the frame rate increases, action appears more natural, but
the file size also increases.
Using the Program mode
In the Program mode, you can set various options except
the shutter speed and aperture value, which the camera sets
automatically.
1
In Shooting mode, press [ ].
2
Select Program.
3
Set options.
(For a list of options, refer to
“Shooting options.”)
4
Align your subject in the frame, and then half-press
[Shutter] to focus.
5
Press [Shutter] to take the photo.

Samsung ES80 Specifications

General

Megapixel	12 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Image sensor size	1/2.3 \
Maximum image resolution	4000 x 3000 pixels
Digital zoom	3 x
Optical zoom	5 x
Focal length range	4.9 - 24.5 mm
Interface	USB 2.0
Digital SLR	No
Minimum RAM	512 MB
Minimum processor	2.2 GHz
Aperture range (F-F)	3.5 - 5.9
Camera shutter speed	1/8 - 1/2000 s
Minimum storage drive space	250 MB
Compatible operating systems	Windows XP/7/Vista Mac G3+/Mac OS 10.4
Focal length (35mm film equivalent)	27 - 135 mm
Focus	TTL
Focus adjustment	Auto
Normal focusing range	0.8 - ∞/1 - ∞ m
Auto focusing (AF) modes	Centre weighted Auto Focus, Multi Point Auto Focus
Macro focusing range (wide)	0.05 - 0.8 m
Normal focusing range (wide)	0.8 - ∞ m
Auto Mode focusing range (tele)	1 - ∞ m
Auto Mode focusing range (wide)	0.05 - ∞ m
Light metering	Centre-weighted, Spot
ISO sensitivity	80, 100, 200, 400, 800, 1600, Auto
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash range (tele)	0.5 - 2 m
Flash range (wide)	0.4 - 3 m
Flash recharging time	4 s
Internal memory	- MB
Compatible memory cards	SD, SDHC
Motion JPEG frame rate	30 fps
Video formats supported	AVI
Maximum video resolution	640 x 480 pixels
Display diagonal	2.36 \
Display resolution (numeric)	110000 pixels
USB version	2.0
Scene modes	Backlight, Beach, Children, Close-up (macro), Dawn, Documents, Fireworks, Night, Night portrait, Portrait, Snow, Sunset, Landscape (scenery)
Image editing	resizing, rotating
Photo effects	Negative film, Vivid
White balance	Auto, Cloudy, Custom modes, Daylight, Fluorescent, Tungsten
Camera playback	movie, single image, slide show, thumbnails
Self-timer delay	2 s
Product color	Silver
Battery type	BP70A
Battery capacity	740 mAh
Power requirements	4.2V
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 85 %

Weight and Dimensions

Depth	20.8 mm
Width	97 mm
Height	58 mm
Weight	124.8 g
