Samsung GALAXY S4 Active User Manual

Installing the SIM Card
When you subscribe to a cellular network, you are provided
with a plug-in SIM card loaded with your subscription details,
such as your PIN, available optional services, and many
others features.
Important! The plug-in SIM card information and its contacts
can be easily damaged by scratching or bending,
so be careful when handling, inserting, or
removing the card. Keep all SIM cards out of reach
of small children.
 Carefully slide the SIM card into the SIM card socket
(as shown) until the card locks into place.
• Make sure that the card’s gold contacts face into the phone
and that the upper-left angled corner of the card is positioned
as shown.
Note: If the card is not inserted correctly, the phone will not
detect the SIM card. Re-orient the card back into the slot
if the SIM is not detected.
Getting Started 7

Samsung GALAXY S4 Active Specifications

General

Processor	Quad-core 1.9 GHz Krait 300
RAM	2 GB
Internal Storage	16 GB
Expandable Storage	microSD, up to 64 GB
Main Camera	8 MP, f/2.6, autofocus, LED flash
Front Camera	2 MP
Battery	Li-Ion 2600 mAh, removable
Operating System	Android 4.2.2 (Jelly Bean), upgradable to 5.0.1 (Lollipop)
Weight	153 g (5.40 oz)
SIM	Micro-SIM
Protection	Corning Gorilla Glass 2
Chipset	Qualcomm APQ8064T Snapdragon 600
GPU	Adreno 320
Loudspeaker	Yes
3.5mm jack	Yes
WLAN	Wi-Fi 802.11 a/b/g/n/ac, dual-band, Wi-Fi Direct, DLNA, hotspot
Bluetooth	4.0, A2DP, EDR, LE
GPS	Yes, with A-GPS, GLONASS
NFC	Yes
Infrared port	Yes
Radio	Stereo FM radio, RDS
Sensors	Accelerometer, gyro, proximity, compass, barometer
Talk time	Up to 17 h (3G)
Colors	Urban Grey, Dive Blue, Orange Flare
Display	5.0 inches, 1080 x 1920 pixels, TFT
Water and Dust Resistance	IP67 certified - dust and water resistant
Dimensions	139.7 x 71.3 x 9.1 mm
USB	microUSB 2.0 (MHL TV-out), USB On-The-Go
