Samsung ML-1670 User Manual

Troubleshooting_ 49
To avoid tearing the paper, pull the jammed paper out slowly and
carefully. Follow the instructions in the following sections to clear the
jam.
In tray
Click this link to open an animation about clearing a jam.
1. Ope
n and close the top cover. The jammed paper is automatically
ejected from the machine.
If the paper does not eject, go to the next step.
2. Remove the jammed
paper by gently pulling it straight out.
If the paper does not move when you pull, or if you do not see the paper
in this area, check inside the machine. (See "Inside the machine" on
page 49.)
Inside the machine
Click this link to open an animation about clearing a jam.
The fuser area is hot. Be careful when removing paper from this area
to prevent getting your fingers burnt.
1. Open and close the top cover. The jammed paper is automatically
ejected from the machine.
If the paper does not eject, go to the next step.
2. Ope
n the top cover.
3. Ope
n the fuser unit cover.
.
4. Remove the jammed paper by gently pulling it straight out.
If you do not see the jammed paper, go to the next step.
5. Pu
ll the toner cartridge out.
6. Remove the jammed paper by gently pulling it straight out.

Samsung ML-1670 Specifications

General

Print Technology	Laser
Print Speed	16 ppm
Resolution	1200 x 1200 dpi
Input Capacity	150 sheets
Output Capacity	100 sheets
Interface	USB 2.0
Dimensions	341 x 224 x 184 mm
Black Print Resolution	1200 x 1200 dpi
Internal Memory	8 MB
Processor Frequency	150 MHz
Printer Type	Monochrome Laser Printer
Supported Operating Systems	Windows, Mac OS, Linux
First Page Out Time	8.5 seconds
Monthly Duty Cycle	5000 pages
Paper Size	A4, Letter, Legal, Executive
Media Types Supported	Plain, Thick, Thin, Cotton, Color, Preprinted, Recycled, Label, Bond, Archive
First Page Out Time (Alternative)	10 seconds
