1.3 <
Introduction>
Rear view
1
control board cover
6
duplex unit
2
network port
a
a. ML-3471ND only.
7
power receptacle
3
USB port
8
power switch
4
parallel port
9
rear cover
5
optional tray 2 cable
connector
* The figure above shows an ML-3471ND with
all available options.
Control panel overview
ML-3470D and ML-3471ND
1
Menu: Enters Menu mode and scrolls through the available
menus.
2
scroll buttons: Scroll through the options available in the
selected menu, and increase or decrease values.
3
OK: Confirms the selection on the display.
4
Back: Sends you back to the upper menu level.
5
Toner Save: Allows you to save on toner by using less toner
in printing.
6
Duplex: Allows you to print documents on both sides of the
paper.
7
Stop: Stops an operation at any time.
8
Status: Shows the status of your printer. See page 1.4.
