Samsung NX2000 User Manual

16
Concepts in Photography
Aperture value and the depth of eld
You can blur or sharpen the background of a photo by controlling the
aperture. It is closely related to the depth of eld (DOF), which can be
expressed as small or large.
A photo with a large DOF A photo with a small DOF
The aperture housing contains several blades. These blades move together and
control the amount of light passing through the center of the aperture. The
number of blades also aects the shape of light when shooting night scenes. If
an aperture has an even number of blades, light divides into an equal number
of sections. If the number of blades is odd, the number of sections is double the
number of blades.
For example, an aperture with 8 blades divides light into 8 sections and an
aperture with 7 blades into 14 sections.
7 blades 8 blades

Samsung NX2000 Specifications

General

Megapixel	20.3 MP
Camera type	MILC
Sensor type	CMOS
Sensor format	Advanced Photo System type-C (APS-C)
Image stabilizer	Yes
Total megapixels	21.6 MP
Image sensor size	- \
Image formats supported	JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 16:9
Maximum image resolution	- pixels
Still image resolution(s)	480 x 480, 640 x 424, 1280 x 1280, 1920 x 1080, 1920 x 1280, 2000 x 2000, 3008 x 1688, 3008 x 2000
Digital zoom	2 x
Optical zoom	- x
Focal length range	50 - 200 mm
Lens mount interface	Samsung NX
Minimum aperture number	-
Minimum focal length (35mm film equiv)	- mm
Auto Focus (AF) points	21
Auto focusing (AF) modes	Continuous Auto Focus, Multi Point Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, Auto
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 3EV (1/3EV step)
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction
Flash sync-speed	0.0055 s
Video resolutions	320 x 240, 640 x 480, 1280 x 720, 1920 x 1080 pixels
Video formats supported	H.264, MP4
Maximum video resolution	1920 x 1080 pixels
Audio formats supported	AAC
Memory slots	1
Internal memory	2048 MB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Field of view	100 %
Display diagonal	3.7 \
Display resolution	800 x 400 pixels
Display resolution (numeric)	1152000 pixels
USB version	2.0
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Fireworks, Night, Panorama, Sunset, Landscape (scenery)
Image editing	Resizing, Rotating
Photo effects	Vivid
White balance	Auto, Cloudy, Custom modes, Daylight, Flash, Fluorescent, Lamp, Tungsten
Camera playback	Movie, Single image, Slide show, Thumbnails
Image processor	DRIMe IV
Self-timer delay	2, 30 s
Languages support	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HEB, HUN, ITA, KOR, LAV, LIT, NOR, POL, POR, RUS, SER, SWE, THA, TUR
Camera file system	DCF, DPOF 1.1, Exif 2.21, RAW
Minimum RAM	512 MB
Minimum processor	Intel Core 2 Duo 2.0 GHz / AMD Phenom 2.4 GHz
Power source type	Battery
Minimum storage drive space	250 MB
Battery type	BP1130
Battery capacity	1130 mAh
Battery life (max)	2.83 h
Battery life (CIPA standard)	340 shots
Product color	White
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 85 %
Cables included	USB
Bundled software	Adobe Photoshop Lightroom 4\\r iLauncher

Weight and Dimensions

Depth	35.7 mm
Width	119 mm
Height	64.5 mm
