Samsung NX2000 User Manual

21
Concepts in Photography
Depth of eld
Portraits or still-life photos mostly acclaimed by people are the ones on
which the background is out of focus so the subject looks pronounced.
Depending on the focused areas, a photo can be blurred or sharpened.
This is called ‘a low DOF’ or ‘a high DOF’.
The depth of eld is the focused area around the subject. Therefore, a
small DOF signies that the focused area is narrow and a large DOF means
the focused area is wide.
A photo with a small DOF, which stresses the subject and makes the rest
of it blurred, can be obtained by using a telescope lens or selecting a low
aperture value. Conversely, a photo with a large DOF which shows all the
elements on the photo sharply focused can be achieved by using a wide
angle lens or selecting a high aperture value.
Small Depth of Field Large Depth of Field
What controls out-of-focus eects?
DOF depends on aperture value
The wider the aperture is (namely the lower the aperture value), the lower
the DOF becomes. Under the condition where the other values including
shutter speed and ISO sensitivity are equal, a low aperture value leads to a
photo with a low DOF.
50 mm F5.7 50 mm F22

Samsung NX2000 Specifications

General

Megapixel	20.3 MP
Camera type	MILC
Sensor type	CMOS
Sensor format	Advanced Photo System type-C (APS-C)
Image stabilizer	Yes
Total megapixels	21.6 MP
Image sensor size	- \
Image formats supported	JPG, MPO, RAW
Supported aspect ratios	1:1, 3:2, 16:9
Maximum image resolution	- pixels
Still image resolution(s)	480 x 480, 640 x 424, 1280 x 1280, 1920 x 1080, 1920 x 1280, 2000 x 2000, 3008 x 1688, 3008 x 2000
Digital zoom	2 x
Optical zoom	- x
Focal length range	50 - 200 mm
Lens mount interface	Samsung NX
Minimum aperture number	-
Minimum focal length (35mm film equiv)	- mm
Auto Focus (AF) points	21
Auto focusing (AF) modes	Continuous Auto Focus, Multi Point Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 200, 400, 800, 1600, 3200, 6400, 12800, 25600, Auto
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 3EV (1/3EV step)
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	Auto, Fill-in, Flash off, Red-eye reduction
Flash sync-speed	0.0055 s
Video resolutions	320 x 240, 640 x 480, 1280 x 720, 1920 x 1080 pixels
Video formats supported	H.264, MP4
Maximum video resolution	1920 x 1080 pixels
Audio formats supported	AAC
Memory slots	1
Internal memory	2048 MB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Field of view	100 %
Display diagonal	3.7 \
Display resolution	800 x 400 pixels
Display resolution (numeric)	1152000 pixels
USB version	2.0
HDMI connector type	Micro
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Fireworks, Night, Panorama, Sunset, Landscape (scenery)
Image editing	Resizing, Rotating
Photo effects	Vivid
White balance	Auto, Cloudy, Custom modes, Daylight, Flash, Fluorescent, Lamp, Tungsten
Camera playback	Movie, Single image, Slide show, Thumbnails
Image processor	DRIMe IV
Self-timer delay	2, 30 s
Languages support	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HEB, HUN, ITA, KOR, LAV, LIT, NOR, POL, POR, RUS, SER, SWE, THA, TUR
Camera file system	DCF, DPOF 1.1, Exif 2.21, RAW
Minimum RAM	512 MB
Minimum processor	Intel Core 2 Duo 2.0 GHz / AMD Phenom 2.4 GHz
Power source type	Battery
Minimum storage drive space	250 MB
Battery type	BP1130
Battery capacity	1130 mAh
Battery life (max)	2.83 h
Battery life (CIPA standard)	340 shots
Product color	White
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 85 %
Cables included	USB
Bundled software	Adobe Photoshop Lightroom 4\\r iLauncher

Weight and Dimensions

Depth	35.7 mm
Width	119 mm
Height	64.5 mm
