Samsung NX3000 User Manual

73
Shooting Functions > AF mode
73
Shooting Functions > AF m
od
e
Shooting Functions
AF mode
Learn how to adjust the camera’s focus according to the subjects.
You can select a focusing mode appropriate to the subject among Single
Auto Focus, Continuous Auto Focus, and Manual Focus. The AF function is
activated when you press [Shutter] halfway. In the MF mode, you have to
rotate the focus ring on the lens to focus manually.
In most cases, you can have a focus by selecting Single AF. Fast moving
subjects or subjects with small shading dierences to the background are
dicult to focus. Select an appropriate focusing mode for such instances.
If your lens has an AF/MF switch, you must set the switch according to
the selected mode. Set the switch to AF when you select Single AF or
Continuous AF. Set the switch to MF when you select Manual Focus.
When your lens has no AF/MF switch, press [F] to select a desired AF
mode.
To set the auto
focus mode,
In Shooting mode, press [F] ĺ an option.
• You can also set the option by pressing [m] ĺ b ĺ AF Mode ĺ
an option in Shooting mode.
• The available options may dier depending on the lens in use.

Samsung NX3000 Specifications

General

Megapixel	20.3 MP
Camera type	Compact camera
Sensor type	CMOS
Image stabilizer	Yes
Total megapixels	21.6 MP
Image sensor size	- \
Image formats supported	JPG, RAW
Supported aspect ratios	1:1, 3:2, 16:9
Maximum image resolution	5472 x 3648 pixels
Image sensor size (W x H)	23.5 x 15.7 mm
Image stabilizer location	Lens
Still image resolution(s)	3888 x 2592, 2976 x 1984, 1728 x 1152, 2736 x 1824, 5472 x 3080, 3712 x 2088, 2944 x 1656, 1920 x 1080, 3648 x 3648, 2640 x 2640, 2000 x 2000, 1024 x 1024,
Optical zoom	- x
Focus	TTL
Focus adjustment	Auto/Manual
Auto focusing (AF) modes	Continuous Auto Focus, Monitoring Auto Focus, Single Auto Focus
Light metering	Centre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity	100, 25600
Light exposure modes	Auto, Manual
ISO sensitivity (max)	25600
ISO sensitivity (min)	100
Light exposure correction	± 3EV (1/3EV step)
Fastest camera shutter speed	1/4000 s
Slowest camera shutter speed	30 s
Flash modes	-
Flash range (wide)	- m
Shoe mounting point type	Hot shoe
Video resolutions	320 x 240, 640 x 480, 1280 x 720, 1920 x 1080 pixels
Motion JPEG frame rate	30 fps
Video formats supported	H.264, MP4
Maximum video resolution	1920 x 1080 pixels
Analog signal format system	NTSC, PAL
Audio system	stereo
Audio formats supported	AAC
Memory slots	1
Internal memory	2000 MB
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Second display	No
Display diagonal	3 \
Display resolution	320 x 480 pixels
Display resolution (numeric)	- pixels
Viewfinder type	Optical
USB version	2.0
USB connector	Micro-USB
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Scene modes	Backlight, Close-up (macro), Night, Night landscape, Night portrait, Panorama, Party (indoor), Portrait, Sunset, Twilight, Landscape (scenery)
White balance	Auto, Cloudy, Custom modes, Daylight, Flash, Fluorescent, Manual, Tungsten
Shooting modes	Aperture priority, Manual, Program, Shutter priority
Camera playback	Movie, Single image, Slide show, Thumbnails
Self-timer delay	2, 3, 5, 10, 12, 20, 30 s
Languages support	ARA, CHI (SIMPL), CHI (TR), CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HEB, HUN, ITA, KOR, LAV, LIT, NOR, POL, POR, RUM, RUS, SRP, SWE, THA, TUR
Bundled software	Adobe Light Room 5, iLauncher, Samsung DNG Converter
Operating temperature (T-T)	32 - 104 °F
Operating relative humidity (H-H)	5 - 85 %
Material	Leather
Product color	White
Battery voltage	3.8 V
Battery capacity	2330 mAh
Battery life (CIPA standard)	370 shots
Power source type	USB

Weight and Dimensions

Depth	39 mm
Width	117.4 mm
Height	65.9 mm
Weight	230 g
