Samsung QM50R User Manual

21
3
Select the product from Display under Display options. Next, select Calibrate.
4
Perform calibration following the onscreen instructions displayed as shown in the image.
To provide calibration samples, tap the crosshair each
time that it appears on the screen.
Right-click anywhere on the screen to return to the
last calibration point. Press the Esc button to close
the tool. Do not change your screen orientation until
you have completed the calibration process.
5
After calibration is complete, the message Do you want to save the calibration data?
appears. Select Yes.
Digitizer Calibration Tool
Yes No
Do you want to save the calibration data?
6
The touchscreen monitor has been calibrated successfully.
"
Selecting Reset will remove the calibration data.

Samsung QM50R Specifications

General

Response time	8 ms
Display diagonal	50 \
Display brightness	500 cd/m²
Display technology	-
Native aspect ratio	16:9
LED backlighting type	Edge-LED BLU
Contrast ratio (typical)	4000:1
High Dynamic Range (HDR) supported	Yes
Dynamic contrast ratio marketing name	Mega Contrast
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	117 W
Processor model	A72
Processor family	ARM Cortex
Processor frequency	1.7 GHz
Purpose	Commercial
RMS rated power	10 W
Number of built-in speakers	2
HDMI ports quantity	3
Package depth	152 mm
Package width	1269 mm
Package height	784 mm
Package weight	17600 g
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Mounting type	Wall
Product color	Black
Product design	Digital signage flat panel
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Placement supported	Indoor
Panel mounting interface	200 x 200 mm

Weight and Dimensions

Display depth	46.3 mm
Display width	1121.4 mm
Display height	643.9 mm
Display weight	13400 g
