Samsung QM50R User Manual

4
Parts
QM32R/Q*43R/Q*49R/Q*50R/Q*55R/
Q*65R/Q*75R/Q*85R/QE82R/QM32R-T/
QM43R-T/QM55R-T
2.5 m
2.5 m
30°
30°
Power button
Power indicator
Remote sensor
4 m
Speaker
"
The colour and shape of parts may differ from what is shown. Specifications are subject to change without
notice to improve quality.
Parts Description
Remote sensor
Press a button on the remote control pointing at the sensor on the front of the product
to perform the corresponding function.
"
Using other display devices in the same space as the remote control of this product
can cause the other display devices to be inadvertently controlled.
Power button Turns the product on or off.
Use the remote control within 2.5 m to 4 m from the sensor on the product at an angle of 30° from the left and
right.
"
To enhance the IR receiver performance, connect an external IR cable (sold separately) to the IR IN port.

Samsung QM50R Specifications

General

Response time	8 ms
Display diagonal	50 \
Display brightness	500 cd/m²
Display technology	-
Native aspect ratio	16:9
LED backlighting type	Edge-LED BLU
Contrast ratio (typical)	4000:1
High Dynamic Range (HDR) supported	Yes
Dynamic contrast ratio marketing name	Mega Contrast
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	117 W
Processor model	A72
Processor family	ARM Cortex
Processor frequency	1.7 GHz
Purpose	Commercial
RMS rated power	10 W
Number of built-in speakers	2
HDMI ports quantity	3
Package depth	152 mm
Package width	1269 mm
Package height	784 mm
Package weight	17600 g
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 80 %
Mounting type	Wall
Product color	Black
Product design	Digital signage flat panel
Anti-glare screen	Always gives an optimal view, even in direct sunlight.
Placement supported	Indoor
Panel mounting interface	200 x 200 mm

Weight and Dimensions

Display depth	46.3 mm
Display width	1121.4 mm
Display height	643.9 mm
Display weight	13400 g
