Cleaning and rearranging the interior of the freezer is a snap.
1. Remove the Glass Shelf by pulling the shelf out as far as it
will go. Then, gently lift it up and remove it.
2.
Remove the Door Bin by holding the door bin with both
hands and then gently lift it up.
3.
Remove the Plastic Drawer by pulling it out and slightly
lifting it up.
4.
Remove the Ice Box from the shelf, then lifting the
shelf up and pulling it out from freezer.
5.
Remove the Front Leg Cover by opening both the freezer
and refrigerator doors, and removing the three screws. Once
the screws are free, detach the cover. To reattach the front
leg cover, place it back in its original position and tighten the
three screws.
Do not use excessive force when removing the cover.
Otherwise, the cover may break and cause injury.
REMOVING THE FREEZER ACCESSORIES
operating the SAMSUNG
side-by-side refrigerator
CAUTION
In case it does not have hooks itself in the back
side for not being tilted,a shelf should be placed
deeply in a proper position where there are blocks
for shelves as shown. if not, the shelf can fall out
of a refrigerator.
Hook
Block
34
