Samsung SCB-2000 User Manual

COLOR CCD CAMERA User Guide
22
COLOR CCD CAMERA User Guide
23
Operating Your Camera
•BecausetherecanbeadifferenceintheeffectivenessofHLCaccordingtotheamountof
lightareainthescreen,optimizetheinstallationangleforthebestHLCperformance.
• Whendark,theHLCisonlyactivatedwhenabrightlightexceedingaspecificsize.inNIGHTONLYmode.
• TheHLCisnotactivatedindaylightorwhenbrightlightisnotpresentatnight.inNIGHTONLYmode.
Notes
This function reduces the background noise in a low luminance environment.
1. When the SETUP menu screen is displayed, select ‘SSNR’ by using the Up and Down
buttons so that the arrow indicates ‘SSNR’ .
2. Select a desired mode using the Left and Right buttons.

OFF : Deactivates SSNR. Noise is not reduced.

ON :ActivatesSSNRsothatnoiseisreduced.
SSNR3
MAIN MENU
1.LENS DC
2.EXPOSURE
3.WHITE BAL ATW
4.SSDR
OFF
5.BACKLIGHT OFF
6.SSNR3 ON
7.DAY/NIGHT COLOR
3. Set the SSNR mode to ‘ON’ and press the SET button. Then you can adjust the noise reduction level.
• YoucannotsettheSSNRto‘ON’or‘OFF’whentheAGCmodeoftheEXPOSUREmenuis‘OFF’.
•WhenadjustingthenoisereductionlevelintheSSNRmode,rememberthatthehigher
the level set, the more the noise level will be reduced, as will the brightness of the image.
Notes
You can display pictures in color or black and white.
1.WhentheSETUPmenuscreenisdisplayed,select‘DAY/NIGHT’byusingtheUpand
Downbuttonssothatthearrowindicates‘DAY/NIGHT’.
DAY/NIGHT
MAIN MENU
1.LENS DC
2.EXPOSURE
3.WHITE BAL ATW
4.SSDR
OFF
5.BACKLIGHT OFF
6.SSNR3 ON
7.DAY/NIGHT COLOR
8.SPECIAL
2. Select a desired mode using the Left and Right buttons according to the picture display you want.

COLOR : The picture is always displayed in color.

B/W : The picture is always displayed in black and white.
You can turn on or off the burst signal on B/W mode.

AUTO :Themodeisswitchedto’Color‘inanormal
environment, but switches to ’B/W‘ mode
when ambient illumination is low. To set up
theswitchingtimeforAUTOmode,pressthe
SET button.
You can turn on or off the burst signal on
B/W mode.
- DWELL TIME : You can select the duration time about
changing the day/night mode. 
5s, 7s, 10s, 15s, 20s, 30s, 40, 60s
•WhenusingaVideoAutoIrisLens,ifyousetthelensleveltolow,automaticswitching
betweenColorandBlack&Whitemaynotoccur.
•WhenAGCintheEXPOSUREmenuis'OFF','---'modeoperatesaslikeselecting'COLOR'
modeand'AUTO'modecannotbeselected.
Notes

Samsung SCB-2000 Specifications

General

Maximum resolution	- pixels
Number of TV lines	600
Supported video modes	-
Camera shutter speed	1/200 s
Minimum illumination	0.0001 lx
Sensor type	CCD
Optical sensor size	1/3 \
Optical zoom	- x
Type	IP security camera
Placement supported	Indoor & outdoor
Connectivity technology	Wired
Mounting type	Ceiling/wall
Product color	Black
Housing material	Aluminium, Steel
Ethernet LAN	No
AC input voltage	230 V
Power consumption (typical)	4 W
Cables included	Coaxial
Operating temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	0 - 90 %
Dimensions (WxDxH)	58 x 121 x 52 mm

Weight and Dimensions

Depth	121 mm
Width	58 mm
Height	52 mm
Weight	510 g
