Samsung Electronics 4-1
Troubleshooting
If the power is not Supplied
Does the
fuses(FP01~FP02)
Work normally?
Does a
voltage-output to the 3pin
of SW206 work normally?
Does a
voltage-output to the L103,
L105, L106, L107, L108 work
normally?
Main board
Repair/replacement
Fuse replacement
Check Power switch (SW206)
Check L103, L105, L106, L107, L108
No
Yes
No
No
Refer to a pattern
image of Table 4-1, 4-2
Refer to a pattern
image of Table 4-1
Yes
Yes
4. Troubleshooting
To Next Page
