● INSTALLATION & CONNECTION
To connect to the alarm input port
Connect the alarm input cable to the corresponding port.
Port Description Port Description
ALARM IN Alarm Input Sensor Port GND GND port for the sensor
To connect the external sensor
Connect one strand of each signal line (2-strand) of the sensors to the [ALARM IN] port,
and connect the other strand to the [GND] port.
SENSOR
B
R
O
W
N
A
L
A
R
M
I
N
B
L
A
C
K
G
N
D
