Page #105 background image
Connecting to a WLAN and conguring network settings
Wireless network
104
Network connection tips
• You must insert a memory card to use the Wi-Fi features.
• The quality of the network connection will be determined by the AP.
• The further the distance between your camera and the AP, the longer it will take
to connect to the network.
• If a nearby device is using the same radio frequency signal as your camera, it may
interrupt your connection.
• If your AP name is not in English, the camera may not be able to locate the device
or the name may appear incorrectly.
• For network settings or a password, contact your network administrator or
network service provider.
• If a WLAN requires authentication from the service provider, you may not be able
to connect to it. To connect the WLAN, contact your network service provider.
• Depending on the encryption type, the number of digits in the password may
dier.
• A WLAN connection may not be possible in all surroundings.
• The camera may display a WLAN enabled printer on the AP List. You cannot
connect to a network via a printer.
• You cannot connect your camera to a network and a TV simultaneously.
• Connecting to a network may incur additional charges. Costs will vary based on
the conditions of your contract.
• If you cannot connect to a WLAN, try another AP from the available AP list.
• A login page may appear when you select free WLANs provided by some
network service providers. Enter your ID and password to connect to the WLAN.
For information about registering or the service, contact the network service
providers.
• Be cautious when you enter personal information for an AP connection. Do not
enter any payment or credit card information on your camera. The manufacturer
is not liable for any problem caused by entering such information.
• Available network connections may dier by country.
• The WLAN feature of your camera must comply with radio transmission laws in
your region. To ensure compliance, use the WLAN feature only in the country
where you purchased the camera.
• The process for adjusting network settings may dier, depending on network
conditions.
• Do not access a network that you are not authorized to use.
• Before you connect to a network, ensure your battery is fully charged.
• You cannot upload or send les captured in some modes.
• Files that you transfer to another device may not be supported by the device. In
this case, use a computer to playback the les.

Table of Contents

Other manuals for Samsung WB30F

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Samsung WB30F and is the answer not in the manual?

Samsung WB30F Specifications

General IconGeneral
Megapixel16.2 MP
Camera typeCompact camera
Sensor typeCCD
Image stabilizerYes
Total megapixels16.6 MP
Image sensor size1/2.3 \
Image formats supportedEXIF, JPG
Maximum image resolution4608 x 3456 pixels
Still image resolution(s)1024 x 768, 1920 x 1080, 1984 x 1488, 2592 x 1944, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom5 x
Optical zoom10 x
Combined zoom50 x
Focal length range4.3 - 43 mm
Maximum aperture number6.3
Minimum aperture number3.1
Maximum focal length (35mm film equiv)240 mm
Minimum focal length (35mm film equiv)24 mm
FocusTTL
Focus adjustmentAuto/Manual
Normal focusing range0.8 - ∞/2.5 - ∞ m
Auto focusing (AF) modesCentre weighted Auto Focus, Continuous Auto Focus, Multi Point Auto Focus, Tracking Auto Focus
Macro focusing range (tele)1.3 - 2.5 m
Macro focusing range (wide)0.05 - 0.80 m
Normal focusing range (tele)2.5 - ∞ m
Normal focusing range (wide)0.8 - ∞ m
Auto Mode focusing range (tele)1.8 - ∞ m
Auto Mode focusing range (wide)0.05 - ∞ m
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity80, 100, 200, 400, 800, 1600, 3200, Auto
Light exposure modes-
ISO sensitivity (max)3200
ISO sensitivity (min)80
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Fastest camera shutter speed1/2000 s
Slowest camera shutter speed16 s
Flash modesAuto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash range (tele)0.5 - 1.6 m
Flash range (wide)0.2 - 3.3 m
Flash recharging time4 s
Power source typeBattery, USB
HD typeNot supported
Video formats supportedMP4
Maximum video resolution1280 x 720 pixels
Analog signal format systemNTSC, PAL
Audio formats supportedAAC
Memory slots1
Internal memory9.5 MB
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size64 GB
Display diagonal3 \
Display resolution (numeric)230000 pixels
HDMINo
USB version2.0
Product colorWhite
Scene modesBacklight, Beach, Candlelight, Close-up (macro), Dawn, Fireworks, Night, Night portrait, Panorama, Portrait, Snow, Spotlight, Sunset, Landscape (scenery)
White balanceAuto, Cloudy, Custom modes, Daylight, Fluorescent H, Fluorescent L, Tungsten
Shooting modesAuto, Movie, Scene
Camera playbackMovie, Single image, Slide show, Thumbnails
Self-timer delay2, 10 s
Mac operating systems supportedMac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Windows operating systems supportedWindows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Battery typeBP70A
Battery voltage3.7 V
Battery capacity740 mAh
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)5 - 85 %
Bundled softwarei-Launcher
Weight and Dimensions IconWeight and Dimensions
Depth16.5 mm
Width98 mm
Height57.9 mm
Weight131 g
