Sending photos or videos via email
Wireless network
114
Sending photos or videos via email
You can send photos or videos stored on the camera via email. For information
about entering text, refer to "Entering text". (p. 105)
1
On the Home screen, scroll to <Wi-Fi>.
2
Select .
• The camera will automatically attempt to connect to a WLAN via the most
recently connected AP device.
• If the camera has not previously been connected to a WLAN, it will search for
available AP devices. (p. 102)
3
Select the Sender box, enter your email address, and then select
Done.
• If you have previously saved your information, it will be inserted
automatically. (p. 112)
• To use an address from the list of previous senders, select
an
address.
4
Select the Receiver box, enter an email address, and then select
Done.
• To use an address from the list of previous recipients, select an
address.
• Select
to add additional recipients. You can input up to 30 recipients.
• Select
to delete an address from the list.
5
Select Next.
6
Scroll to les to send, and then press [ ].
• You can select up to 20 les. The total size must be 7 MB or less.
7
Select Next.
8
Select the Comment box, enter your comments, and then select
Done.
9
Select Send.
• The camera will send the email.
• Even if a photo appears to have transferred successfully, errors with the
recipient’s email account may cause the photo to be rejected or recognized as
spam.
• You may not be able to send an email if no network connection is available or if
your email account settings are incorrect.
• You cannot send an email if the le size exceeds the limit. The maximum
photo resolution you can send is 2M and the longest video you can upload is
30 seconds at
resolution or a video recorded using . If the selected
photo resolution is higher than 2M, it will be automatically resized to a lower
resolution.
• If you cannot send an email because of rewall or user authentication settings,
contact your network administrator or network service provider.
• When there are no les in the camera memory, you cannot use this feature.
• You can also send an email in Playback mode by pressing [
], and then
selecting Share(Wi-Fi) Email.

Table of Contents

Other manuals for Samsung WB30F

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Samsung WB30F and is the answer not in the manual?

Samsung WB30F Specifications

General IconGeneral
Megapixel16.2 MP
Camera typeCompact camera
Sensor typeCCD
Image stabilizerYes
Total megapixels16.6 MP
Image sensor size1/2.3 \
Image formats supportedEXIF, JPG
Maximum image resolution4608 x 3456 pixels
Still image resolution(s)1024 x 768, 1920 x 1080, 1984 x 1488, 2592 x 1944, 4608 x 2592, 4608 x 3072, 4608 x 3456
Digital zoom5 x
Optical zoom10 x
Combined zoom50 x
Focal length range4.3 - 43 mm
Maximum aperture number6.3
Minimum aperture number3.1
Maximum focal length (35mm film equiv)240 mm
Minimum focal length (35mm film equiv)24 mm
FocusTTL
Focus adjustmentAuto/Manual
Normal focusing range0.8 - ∞/2.5 - ∞ m
Auto focusing (AF) modesCentre weighted Auto Focus, Continuous Auto Focus, Multi Point Auto Focus, Tracking Auto Focus
Macro focusing range (tele)1.3 - 2.5 m
Macro focusing range (wide)0.05 - 0.80 m
Normal focusing range (tele)2.5 - ∞ m
Normal focusing range (wide)0.8 - ∞ m
Auto Mode focusing range (tele)1.8 - ∞ m
Auto Mode focusing range (wide)0.05 - ∞ m
Light meteringCentre-weighted, Evaluative (Multi-pattern), Spot
ISO sensitivity80, 100, 200, 400, 800, 1600, 3200, Auto
Light exposure modes-
ISO sensitivity (max)3200
ISO sensitivity (min)80
Light exposure controlProgram AE
Light exposure correction± 2EV (1/3EV step)
Fastest camera shutter speed1/2000 s
Slowest camera shutter speed16 s
Flash modesAuto, Fill-in, Flash off, Red-eye reduction, Slow synchronization
Flash range (tele)0.5 - 1.6 m
Flash range (wide)0.2 - 3.3 m
Flash recharging time4 s
Power source typeBattery, USB
HD typeNot supported
Video formats supportedMP4
Maximum video resolution1280 x 720 pixels
Analog signal format systemNTSC, PAL
Audio formats supportedAAC
Memory slots1
Internal memory9.5 MB
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size64 GB
Display diagonal3 \
Display resolution (numeric)230000 pixels
HDMINo
USB version2.0
Product colorWhite
Scene modesBacklight, Beach, Candlelight, Close-up (macro), Dawn, Fireworks, Night, Night portrait, Panorama, Portrait, Snow, Spotlight, Sunset, Landscape (scenery)
White balanceAuto, Cloudy, Custom modes, Daylight, Fluorescent H, Fluorescent L, Tungsten
Shooting modesAuto, Movie, Scene
Camera playbackMovie, Single image, Slide show, Thumbnails
Self-timer delay2, 10 s
Mac operating systems supportedMac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion
Windows operating systems supportedWindows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Battery typeBP70A
Battery voltage3.7 V
Battery capacity740 mAh
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)5 - 85 %
Bundled softwarei-Launcher
Weight and Dimensions IconWeight and Dimensions
Depth16.5 mm
Width98 mm
Height57.9 mm
Weight131 g
