S&C 2010 User Manual

S&C ELECTRIC COMPANY
s
716-501
INSTRUCTION SHEET
Page 24 of 26
August 12, 2002
S&C Series 2000 Circuit-Switchers Model 2010 — With Horizontal Interrupters and
Outdoor Transmission (69 kV through 230 kV) Vertical-Break Power-Operated Disconnect
Eight nonadjustable single-pole
double-throw auxiliary-switch contacts
(not visible in photo) which follow the
interrupters
Weatherproof,
dustproof enclosure
Side access door for user’s
external connections
(to terminal blocks at bottom
of enclosure)
Trip and close
push buttons
Position-indicating
lamps (Catalog
Number Suffix “-M”)
Duplex receptacle
with ground-fault
circuit interrupter
and convenience-
light lamp holder
with switch (Catalog
Number Suffix “-V”)
Non-reset electric
operation counter
Charged and discharged
indicators for stored-
energy mechanism
Control-source
disconnect switch
Motor-and-closing
circuit fuseholder
Space-heater
fuses
Conduit
entrance plate
Three-
point
door
latch
Spare
fuses
Instruction
manual
holder
Manual trip lever
Motor
Door gasket
Key interlock
(Catalog Number
Suffix “-L1”) (not
visible in photo)
Two individually adjustable auxiliary-
switch contacts which follow the discon-
nect-blade power train and operator when
coupled, operator only when decoupled
Manual operating
shaft
Access shutter
Manual
charging
holder
Optional remote
gas-density monitor
(receiver)
OPERATION — Continued
Figure 15. Interior of operator.
