Service Manual SM CE29FFV1-F
2
5. TECHNICAL CHARATERISTICS.
Cathode-ray tubes
In-Line, gun Type. Black Matrix. 29” (68 cm) True Flat, Invar Plus mask.
Tuning-system
Voltage synthesis, 100 programs in non-volatile memory, AFT, automatic,
semiautomatic and manual channel-search.
Reception channels
Band I, channels 2-4 (VHF)=E2-E4
Cable channels S1-S10
Hyperband channels S21-S41
Band III, channels 5-12 (VHF)=E5-E12
Band IV-V, channels 21-69 (UHF)=E21-E69
Reception system
B/G, D/K, I, L, L' system
Colour system
PAL, SECAM, (NTSC 4.43, NTSC 3,58) ONLY AV
Program selection
Sequential selection from the controls on the set. Direct selection to any program
from the remote-control device.
Audio
Power-rating 2x8,9 W rms. (10% distortion)
Speakers
2 of 8
Ω
.
Aerial
External aerial sockets 75 Ωs. IEC
Jack for headphones
Stereo jack 3,5mm. (with independent control)
Clock and alarm Function
Timer Function
Switch on and off of CTV programmable in real time.
AV connectors
1 Scart connector 21 pin CENELEC standard AV, RGB and S_Video.
1 Scart connector 21 pin CENELEC standard AV, RGB
1 RCA Video input (frontal)
2 RCA Audio input (frontal)
Power supply
220 – 240 VAC 50Hz
Consumption
83 W (IEC 107-1)
2,1 W (Stand-by
)
CTI
Improves color transitions
Comb Filter
Improves video bandwith and reduces crosscolor effect.
Stereo/Dual Systems
NICAM and Stereo/Dual (A2)
Sound Effects
Pseudo Stereo. Bass boost. Actv. 3D sorround, BBE, spatial stereo
Auto volume
Clock function
Alarm function
Programmable over 24 hours
Timer function
Switch on and off are programmable aver 24 hours.
TXT
1,5 Flot and list. 10 Teletext pages memory
Hotel Mode
It can be programmed in Hotel Mode and Rental Hotel Mode
Remore ON/OFF
Tis TV can be switched ON/OFF Through the blue scart connector.
Options by means of Technical Service:
SECAM, NTSC-M
6. Safety
It fulfils the safety requirements established in the regulation:
EN 60065:98
7. EMC (Electromagnetic Compatibility)
It fulfils the EMC requirements established in the regulation:
EN 55013:1990/A12:1993/A13:1996/A14:1999
EN 55020:1994/A11:1996/A13:1999/A14:1999
EN 61000-3-2:1995+A1:19998+A2:98/A14:2000
EN 61000-3-3:1995
8. Factory special mode
The factory mode is a special TV working mode intended to help in the manufacturing process and it is identified on
the screen with the message “FAC”. This mode is never suited for customer use.
The main differences respect to normal mode are:
1- The standby mode is always disabled.
2- The Blue-back (no sync. signal present) is disabled.
3- The customer adjustments ( volume, contrast …) work faster.
4- The timer off works but it does not change to Stand-by mode.
5- Change of programs and TV/AV swithing faster. Cancelled mute.
In case of finding the TV set in Factory mode, it must be taken out of this state. To do so, enter the clock setting
menu on the customer OSD and then exit.
