English - 10 -
Viewing the Connections - Side Connectors
CI Slot is used for inserting a CI card. A CI card allows you 1.
to view all the channels that you subscribe to. For more
information, see “Conditional Access” section.
Side USB input . 2.
Note: Codec update cannot be performed.
Headphone jack is used for connecting an external 3.
headphone to the system. Connect to the HEADPHONE
jack to listen to the TV from headphones (optional).
Video Input is used for connecting video signals of 4.
external devices.Connect the video cable between the
VIDEO IN socket on the TV and the VIDEO OUT jack on
your device.
Audio Inputs are used for connecting audio signals of 5.
external devices. Connect the audio cable between the
AUDIO INPUTS on the TV and the AUDIO OUTPUT jacks
on your device. Note: If you connect a device to the TV via
the VIDEO INPUT, you should also connect your device
with an audio cable to the AUDIO INPUTS of the TV to
enable audio.
