Sanyo CWM-240 User Manual

- 10 -
EXPLODED VIEW & PARTS LIST (TAPE DECK MECHANISM)
TM06
TM05
TM04
TM02
TM01
TM03
TAPE DECK MECHANISM CHASSIS
REF.NO. PART NO. DESCRIPTION
81 645 050 1814 CASS DECK MECHANISM
TM01 645 018 0637 R/P HEAD
TM02 645 050 0985 PINCH ROLLER ARM
TM03 645 030 6839 E HEAD
TM04 645 050 1395 RF BELT
TM05 645 050 1784 MAIN BELT
TM06 645 050 2101 ASSY,MOTOR
1
234
5
678
9
10 11 12
24
23 22 21
20
19 18 17
16
15 14 13
FM
RF
AM
RF
AM
MIX
FM
MIX
FM
OSC
AM
OSCREG Vcc1
Vcc2GND2
GND1
DECODER
PHASE
COMP
PILOT
DET
TRIG ST-SW VCO
DET
DET
AM-IF
S-METER
FM-IF
AGC
FF FF FF
ST
LED
TUN
LED
IC BLOCK DIAGRAM & DESCRIPTION
IC101 LA1824 (Tuner)
28 27 26 25 24 23 22 21 20 19 18 17 16 15
1234567 891011121314
Vcc
Vcc
DRIVER MUTE
D.BUFD.BUFD.BUFD.BUF
D.BUFD.BUFD.BUFD.BUF
Level shift
Level shift
Level shift
Level shift
T. S. D
IC903 MM1569XH (CD Driver)
IC201 TA2068 (Cassette Priamp.)
