PARTS LIST
PRODUCT SAFETY NOTICE
EACH PRECAUTION IN THIS MANUAL SHOULD BE FOLLOWED DURING SERVICING. COMPONENTS IDENTIFIED WITH THE IEC
SYMBOL
!
!!
IN THE PARTS LIST AND THE SCHEMATIC DIAGRAM DESIGNATED COMPONENTS IN WHICH SAFETY CAN BE OF
SPECIAL SIGNIFICANCE. WHEN REPLACING A COMPONENT IDENTIFIED BY
!
!!
, USE ONLY THE REPLACEMENT PARTS DESIGNATED,
OR PARTS WITH THE SAME RATINGS OF RESISTANCE, WATTAGE OR VOLTAGE THAT ARE DESIGNATED IN THE PARTS LIST
IN THIS MANUAL. LEAKAGE-CURRENT OR RESISTANCE MEASUREMENTS MUST BE MADE TO DETERMINE THAT EXPOSED
PARTS ARE ACCEPTABLY INSULATED FROM THE SUPPLY CIRCUIT BEFORE RETURNING THE PRODUCT TO THE CUSTOMER.
CAUTION : Regular type resistors and capacitors are not listed. To know those values, refer to the schematic diagram.
Regular type resistors are less than 1/4 W carbon type and 0 ohm chip resistors.
Regular type capacitors are less than 50 V and less than 1000 µF type of Ceramic type and Electrical type.
PACKING & ACCESSORIES
REF.NO. PART NO. DESCRIPTION
614 314 1358 CARTON CASE(UK)
614 315 7953 CARTON CASE(XE)
614 314 1365 CUSHION,REAR
614 314 1372 CUSHION,FRONT
614 314 1396 INSTRUCTION MANUAL(UK)
614 316 3107 INSTRUCTION MANUAL(XE)
614 245 8587 NOTICE,AC CODE(UK)
645 043 7366 POLY SHEET-0380X0300*NC(UK)
645 043 7373 POLY SHEET-0380X0300*NC(XE)
645 005 1227 ASSY,ANTENA,LOOP
645 040 3217 REMOCON,RB-DA70
or 645 042 3604 REMOCON,RB-DA70
or 645 042 3611 REMOCON,RB-DA70
614 229 4635 ANTENNA (XE)
or 614 308 5515 ANTENNA (XE)
614 314 8975 ASSY,BOX,SPEAKER(UK)
614 314 8982 ASSY,BOX,SPEAKER(XE)
CABINET & CHASSIS
REF.NO. PART NO. DESCRIPTION
1 614 314 1082 ASSY,DOOR,DECK
2 614 314 1334 SPRING,DOOR DECK
3 614 303 5718 KNOB,VR
4 614 314 1099 ASSY,PANEL,FRONT
5 614 309 7969 ASSY,GEAR,(CASSETTE)
6 614 314 1211 KNOB,DECK,MECHA,REC
7 614 314 1228 KNOB,DECK,MECHA,PLAY
8 614 314 1235 KNOB,DECK,MECHA,REW
9 614 314 1242 KNOB,DECK,MECHA,FFWD
10 614 314 1259 KNOB,DECK,MECHA,STOP/EJECT
11 614 314 1266 KNOB,DECK,MECHA,PAUSE
12 614 314 1297 MOUNTING,DECK
13 614 314 1143 BUTTON,OPERATION,7 KEYS
14 614 314 1136 BUTTON,RIGHT,4 KEYS
16 614 310 3899 SPACER,MECHA
17 614 307 2072 COVER,PICK-UP
18 614 307 8784 LEVER
19 614 314 1303 MOUNTING,CD
20 614 317 5373 ASSY,GEAR,(LID,CD)
21 614 314 1341 SPRING,DOOR CD
22 614 314 1129 BUTTON,CD OPEN,1 KEY
23 614 307 8821 PULLEY
24 614 303 0256 LATCH,MAGNET
25 614 314 1280 LID,CD
26 614 314 7497 COVER
27 614 314 1181 DEC,WINDOW,CD
28 614 314 1105 BUTTON,POWER,1 KEY
29 614 314 1327 SPRING,REC
30 614 314 7541 MOUNTING
31 614 308 4914 STOPPER
32 614 314 1075 ASSY,CABINET,REAR(UK)
32 614 316 3060 ASSY,CABINET,REAR(XE)
33 614 307 9804 ASSY,MECHA,CDDA11-SASH
FIXING PARTS
REF.NO. PART NO. DESCRIPTION
Y01 411 021 3107 SCR S-TPG BIN 2.6X8,
F-PANEL+MTG DECK KNOB
Y02 411 021 3503 SCR S-TPG BIN 3X10,
MTG CD+FRONT PCB
Y03 411 021 3503 SCR S-TPG BIN 3X10,
MTG CD+CD PCB
Y04 411 021 1806 SCR S-TPG BIN 2.6X10,MTG CD+DA11
Y05 411 092 0906 WASHER Z 2.6X10X0.5,MTG CD+DA11
Y06 411 021 3503 SCR S-TPG BIN 3X10,
MTG CD+TUNER PCB
Y07 411 098 4700 SCR S-TPG BIN 2.3X8,
DEC WINDOW CD+LID CD
Y08 411 021 3503 SCR S-TPG BIN 3X10,
MTG CD+MAIN PCB
Y09 411 021 3503 SCR S-TPG BIN 3X10,
REAR+DECK MECHA,
MOUNTING+DECK MECHA
Y10 411 126 1404 SCR S-TPG BIN 2X4,
SPRING DECK REC
Y11 411 020 9100 SCR S-TPG BRZ+FLG 3X12,
REAR+P-TRANS
Y12 411 098 7800 SCR S-TPG FLT 3X12,
C-REAR(L/R SIDE)
Y13 411 021 4500 SCR S-TPG BIN 3X16,C-REAR
Y14 411 021 3503 SCR S-TPG BIN 3X10,
C-REAR(ANT TERMINAL)
Y15 411 021 3503 SCR S-TPG BIN 3X10,MTG CD+REAR
Y16 411 021 3503 SCR S-TPG BIN 3X10,SUB-WOOFER
Y17 411 021 4005 SCR S-TPG BIN 3X12,REAR+STOPPER
ELECTRICAL PARTS
REF.NO. PART NO. DESCRIPTION
51 614 316 3602 FLEXIBLE FLAT CABLE,AMP-FRONT
52 614 316 3619 FLEXIBLE FLAT CABLE,TU-FRONT
53 614 310 9822 WIRE,UL1533-AWG26B,TU-FRONT
54 614 313 7023 FLEXIBLE FLAT CABLE,
CD-PICK UP-CD
or 614 310 5459 FLEXIBLE FLAT CABLE,
CD-PICK UP-CD
55 614 309 8454 ASSY,WIRE,CD-PICK UP-CD
or 614 314 4779 ASSY,WIRE,CD-PICK UP-CD
56 614 274 2013 CORD,ID CONNECTOR,FM ANT(UK)
57
!
!!
423 016 7908 FUSE 250V 2.5A
58 614 314 4786 ASSY,WIRE,R/P HEADS-AMP
or 614 309 8799 ASSY,WIRE,R/P HEADS-AMP
59 614 314 4793 ASSY,WIRE,MECHA SW-AMP
or 614 309 8805 ASSY,WIRE,MECHA SW-AMP
60
!
!!
645 036 9803 CORD,POWER-1.6MK(UK)
or
!
!!
645 036 9797 CORD,POWER-1.6MK(UK)
60
!
!!
645 016 9939 CORD,POWER-1.74MK(XE)
61
!
!!
645 038 7555 TRANS,POWER
To Next Page
