Sanyo DC-MCR50 User Manual

- 4 -
PACKING & ACCESSORIES
REF.NO. PART NO. DESCRIPTION
645 062 1918 INSTRUCTION MANUAL
645 027 2073 POLY BAG,PWR CORD
645 044 1943 POLY BAG,I/B
645 062 2014 POLY BAG,UNIT
645 062 2007 POLY BAG,SPK
645 062 2021 POLY FOAM,KIT
645 062 2083 CARTON CASE
!
!!
645 023 3463 POWER CORD
645 061 6280 REMOTE CTL,RC29-100000-010
645 061 6297 ANTENNA LOOP
62 645 062 0652 SPK BOX L,LEFT
63 645 062 0669 SPK BOX R,RIGHT
PARTS LIST
CAUTION : Regular type resistors and capacitors are not listed. To know those values, refer to the schematic diagram.
Regular type resistors are less than 1/4W carbon type and 0 ohm chip resistors.
Regular type capacitors are less than 50V and less than 1000µF of Ceramic type and Electrolytic type.
PRODUCT SAFETY NOTICE
EACH PRECAUTION IN THIS MANUAL SHOULD BE FOLLOWED DURING SERVICING. COMPONENTS IDENTIFIED WITH
THE IEC SYMBOL
!
!!
IN THE PARTS LIST AND THE SCHEMATIC DIAGRAM DESIGNATE COMPONENTS IN WHICH SAFETY
CAN OF SPECIAL SIGNIFICANCE. WHEN REPLACING A COMPONENT IDENTIFIED , USE ONLY THE REPLACEMENT
PARTS DESIGNATED, OR PARTS WITH THE SAME RATINGS OF RESISTANCE, WATTAGE OR VOLTAGE THAT ARE
DESIGNATED IN THE PARTS LIST IN THIS MANUAL. LEAKAGE-CURRENT OR RESISTANCE MEASUREMENTS MUST
BE MADE TO DETERMINE THAT EXPOSED PARTS ARE ACCEPTABLY INSULATED FROM THE SUPPLY CIRCUIT BEFORE
RETURNING THE PRODUCT TO THE CUSTOMER.
CABINET & CHASSIS
REF.NO. PART NO. DESCRIPTION
1 645 062 1659 CD DOOR
2 645 062 1437 CD DOOR BKT
3 645 062 1567 CD DOOR LENS
4 645 062 0591 ASSY CABINET TOP
6 645 062 1383 PULLEY WORM GEAR
7 645 062 1284 CD DOOR GEAR
8 645 062 1376 MOTOR PULLEY
9 645 062 1420 MOTOR BKT
11 645 062 1611 TRANSPARNT LENS L
12 645 062 1628 TRANSPARNT LENS R
15 645 062 1338 KNOB BASS
16 645 062 1321 KNOB TUNING
17 645 062 1369 KNOB PRESS
18 645 062 1505 KNOB CD DOOR,OPEN
19 645 062 1512 KNOB FUNCTION
20 645 062 1352 KNOB SW,MONO/STEREO
21 645 062 1574 CD DISPLAY LENS
26 645 062 1345 KNOB VOLUME
27 645 062 1208 CD DECK MECHANISM
28 645 033 3446 RUBBER SILICON,HARDNESS
29 645 027 1373 WASHER METAL
30 645 062 1635 CAB REAR COVER,
HEAT SINK COVER
31 645 062 1222 HEAT SINK
33 645 062 1307 CABINET MIDDLE
34 645 062 1482 PANEL SIDE L,LEFT
35 645 062 1499 PANEL SIDE R,RIGHT
36 645 062 1406 AC SOCKET BKT
40 645 033 0391 AC SKT COVER
43 645 055 7514 REMOTE RECEIVER BKT
45 645 062 1598 DECOR FRANT LENS
46 645 062 1314 CABINET BOTTOM
47 645 062 1536 REMOTE LENS
48 645 062 1642 CABINET TOP
49 645 062 0584 ASSY CABINET BOTTOM
FIXING PARTS
REF.NO. PART NO. DESCRIPTION
S10 645 023 6594 SCREW ST 3X8,DISPLAY BD
S11 645 023 6594 SCREW ST 3X8,ANT JACK,
OPTICAL JACK
S13 645 023 6594 SCREW ST 3X8,AUX JACK,
RCA JACK
S14 645 062 1116 SCR 3X15,CAB BTM TO CAB TOP
S16 645 023 6617 SCREW ST 3X10,AC SOCKET
S17 645 023 6594 SCREW ST 3X8,H/JACK BD
S18 645 023 6594 SCREW ST 3X8,MAIN BD
S1 645 062 1086 SCR 2X5,CD DOOR LENS
S2 645 062 1109 SCR 2.6X4,MOTOR
S3 645 023 6594 SCREW ST 3X8,MOTOR BKT
S4 645 027 1168 SCR 3X8,CD DOOR SW
S5 645 062 1116 SCR 3X15,
PWR TRANS TO CAB BTM
S6 645 023 6594 SCREW ST 3X8,
H/S COVER TO CD TRAY
S7 645 023 6587 SCREW ST 3X8,IC TO H/S
S8 645 023 6594 SCREW ST 3X8,AUDIO BD
S9 645 033 0247 SCR 2.6X8,CD DECK
ELECTRICAL-PARTS
REF.NO. PART NO. DESCRIPTION
5 645 062 1215 CD DOOR MOTOR
14
!
!!
645 062 0683 PWR TRANS,9023FS
39 645 032 9760 AC SOCKET S-1-1225
645 062 0928 2P CONNECTOR,SPEAKER
645 042 9569 HSG 6P,MAIN CN902 TO CD DECK
645 062 1000 HSG 2P,MAIN CN706 TO LED BD
645 062 1017 HSG 4P,MAIN CN704 TO CN804
645 062 1024 HSG 4P,MAIN CN303 TO CN305
645 062 1031 HSG 5P,MAIN CN301 TO CN801
645 062 1048 HSG 7P,MAIN CN302 TO CN304
645 062 1055 HSG 14P,MAIN CN703 TO CN708
645 062 1062 HSG 5P,
MAIN CN903 TO CD DOOR SW
645 062 1079 FFC CABLE 16P,
MAIN CN901 TO CD DECK
645 062 1185 HSG 12P,MAIN CN701 TO CN709
645 062 1192 HSG 13P,MAIN CN702 TO CN707
